Gas pressure sintered silicon nitride (GPSSN) is a sintering processing at high temperature after isostatic pressing of silicon nitride powder with other additives. The nitrogen pressure (<20mpa) during sintering could restrain the dissociation of si3n4 and get the full sintering at high temperature, which make the silicon nitride products to highest density and lowest porosity.
Types |
Gas Si3N4 |
Density |
>3.2g/cm3 |
Si3N4 content |
>92% |
Flexural strength |
>600Mpa |
Compressive strength |
>1500Mpa |
Thermal conductivity(W/mk) |
16-22 |
Porosity |
0 |
Thermal expansion coeff.(RT-1000℃) |
3.2 |
|
Max temperature In air |
1400℃ |
Hardness(HRA) |
>92 |
1. Moulding: Cold isostatic pressing(CIP)
2. Sintering: GPSN/RSSN
3. High strength and good compactness
4. Low thermal expansion coefficient
5. Excellent thermal shock resistance
6. No wetting by molten aluminum and non-ferrous metal
7. Good corrosion resistance
Common size:
We can prodcue according to your drawing.
