HOWO 8T truck mouted crane
- 100 Unit / Units per Month
- TIANJIN
- T/T Credit Card
Product Details
Condition: | New | Max. Lifting Load: | 8000kg | Max. Lifting Height: | 12.5m |
Place of Origin: | Shandong, China | Brand Name: | HOWO | Model Number: | SQ8SK3Q |
Certification: | ISO | Warranty: | 12months | After-sales Service Provided: | Overseas service center available |
Product Description
HOWO 8T truck mouted crane
Model
| Chassis ZZ1257N4347D1B |
Arm SQ8SK3Q | |
Crane weight | 3300kg |
Max lifting capacity | 8000kg |
Max lifting moment | 20T.M |
Recommend power | 27kw |
Max pressure of hydraulic system | 27Mpa |
Max oil flow of hydraulic system | 55L/min |
Oil tank capacity | 160L |
Installation space | 1200mm |
Rotation angle | 360° all rotation |
Engine | D10.34-40,249KW 340HP,Euro IV emission standard In-line,six cylinders,water cooling,four strokes,inter cooling,rear supercharger |
Displacement (L) | 9.726 |
Cab | HW76 Extended cab,single berth, up-down,front-rear adjustable steering wheel,VDO instrument and control module, double-locking safety belt,outer sun shade,A/C |
Transmission | HW19710,SINOTRUK ten speed gear-box,auxiliary gear box planetary gear structure |
Steering | ZF8098,German hydraulic steering with power assistance |
Number of axle | 3 |
Wheel base(mm) | 4325+1350 |
Driving axle | HC16 casting axle speed ratio:4.42 |
Front axle | HF9 HOWO new off road 9T front axle,with disc braking system |
Approach/departure angle(°) | 16/15 |
front/rear Overhang (mm) | 1500/2625 |
Tires | 12.00-20,bias tire,10pcs,with one spare tire |
Max. Speed km/h | 102 |
Cargo box size(mm) | 7100*2300*600 thickness floor 3 side 1.5mm |
Dimensions(mm) | 9800*2490*3215 |
DETAILS
Q.WARRANTY
It is 12 months or 60,000 km whichever comes first.
Q.Maintenance
Excellent part supply system ensures usual operation of machine within and outside guarantee period.
Q.How about your product quality?
The products with SUNCAP,SGS,ADR,CIQ,CNC,TISI qualification certification,the quality is 100% guaranteed.
Q. How about your company's service, especially after-sale service?
Our promise “Customer first,Quality first and Credit first”.Five tracking services are made within guarantee period.
Drivers can be trained free of charge according to needs.
SINOTRUK has an annual output of 180,000 vehicles and 200,000 engines capacity.
The subsidiary companies of SINOTRUK including Jinan Truck Co.,Ltd,Jinan Commercial Truck Co.,Ltd and Jinan Power Co.,Ltd etc.The complete trucks include SITARK,HOWO,HOHAN,STR etc of the cargo trucks,dump trucks,tractor heads,trailers,concrete mixer trucks,tanker trucks,light trucks,bus as well as many special vehicles with the horse power range from 266 to 420HP.
