Home > Consumer Electronics > Washing & Drying Machine & Parts > Washing Machine Parts > Copper Winding Wash Machine Parts

Copper Winding Wash Machine Parts

US$ 3 - 13 MOQ: 500 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

YCB

Model Number:

Contact Supplier Request Quote Chat Now

Zhejiang Yongchang Electric Corporation

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name YCB

Model Number XD

Specifications

wash motor
1,hi-tech and good price
2,strong ability for supply
3,smooth running
4,low noise,various kinds

1,Specification

The motors can be customized according to the customers need with different Voltage,Frequency ,etc.

Shape and the size of installation:

Code	A	B	C	D	L1	L2	L3	L4	L5
Size	22	Φ 12	15	160	58	135	45	115	28
	20	Φ 10	15	160	55	130	40	115	28
	18	Φ 12	17	160	52	126	36	111	28

2,Performance parameters

The specification of our general products as below:

Model	Voltage(V)	Frequency(Hz)	capacitance(uF)	Insulation class	Rated speed(r/min)	Output power(W)	efficiency(%)	Starting torque(N.m)	Greatest torque(N.m)
XD-220	220	50	15	E	1350	220	55	1.5	2.2
XD-200	220	50	14	E	1350	200	53	1.4	2
XD-180	220	50	13	E	1350	180	52	1.3	1.8
XD-150	220	50	13	E	1350	150	50	1.25	1.7

3,Raw Material

Silicon Steel for Rotor and Stator

Steel for Shaft

Iron or Aluminum Cover

Copper or Aluminum enameled wire

4,Manufacturing process

5,Packing detail

4 pcs one carton with foam

one container (20GP)containing 6000pcs

One pallet 252 pcs for spin motor.

One pallet 216 pcs for wash motor.

One container (20GP)containing 20 pallet

Can be customized according to customer’s requirement packaging.

6,Why choose us

1) Safe and reliable, low noise, good starting, long life, etc.

2) All our products pass the CE/CCC/ROHS/SGS/ISO9001/TUV/BV

2) This motor can be designed and produced according to your request.

3) We will send you some samples for your further inspecting.

4) We have more detailed specifications.If you are interested in, please mail us.

7,Certification,Patent,ISO

All our products passed the CE/CCC/ROHS/SGS/ISO9001:

If you have further questions , please mail us ! We will meet your requirements.

Sales Department

Tel:86-150 0582 3916

Email:jane@

Skype:jane.shi33

Web:

Our company was established in 1994,it occupied a land area of 20280 square meters and specialized in micro-motors manufacturing. Owing good service,variety of high quality products and competitive price. We ensure efficient delivery,enjoying a good reputation among our customers.
