stone separator, vibrating stone separator is a new type of multi-layer, stone separator, vibrating stone separator is with adjustable amplitude, material screen of long line, multi-layer screen separation, clear screening of each specification, high efficiency of screening and it is widely used for product grading in departments of mining area, sandstones, building materials, transportation, energy, chemical industry, etc.
(Note: our company can provide china vibrating screen of different specification and various vibration types according to the requirements of the consumers.)
stone separator, vibrating stone separator application
stone separator, vibrating stone separator is widely used for grading and screening materials in the following fields: minerals, quarry, building materials, water conservancy and hydropower, transportation, chemical industry, smelting and so on. For material quality of screen mesh is changeable, the application is quite extensive.
stone separator, vibrating stone separator feature
The performance features of stone separator, vibrating stone separator :
stable vibration, reliable work, long life; adjustable exciting force, casual adjustment and control of screening quantity, convenient and stable adjustment; using vibration generator as exciting source, low noise, low power consumption, good adjustment performance without punching materials; simple structure, reliable operation, easy adjustment and assembly, light, small, convenient maintenance and dust prevention when in closed body.
stone separator, vibrating stone separator structure
| Model | Layers | Screen Area (m²) | Sieve Pore Size (mm) | Spec. of Screen (mm) | Max. Feed Size (mm) | Capacity (t/h) | Vibrating Frequency (Hz) | Double Amplitude (mm) | Power (Kw) | Weight (Excluding Motor) (t) | Overall Dimension (LxWxH) (mm) |
| 2YA1237 | 2 | 4.44 | 3~50 | 1200x3700 | 200 | 7.5~80 | 800~970 | 8 | 5.5 | 2.34 | 4642x2250x2659 |
| 3YA1237 | 3 | 4.44 | 3~50 | 1200x3700 | 200 | 7.5~80 | 800~970 | 8 | 7.5 | 3.05 | 4898x2250x3133 |
| 2YA1548 | 2 | 7.2 | 5~50 | 1500x4800 | 400 | 50~208 | 970 | 8 | 15 | 5.33 | 5802x2585x3053 |
| 3YA1548 | 3 | 7.2 | 5~50 | 1500x4800 | 400 | 50~250 | 970 | 8 | 15 | 6.07 | 6046x2585x3537 |
| 2YA1848 | 2 | 8.64 | 5~80 | 1800x4800 | 400 | 50~260 | 970 | 8 | 18.5 | 6.65 | 5802x2947x3053 |
| 3YA1848 | 3 | 8.64 | 5~80 | 1800x4800 | 400 | 50~300 | 970 | 8 | 18.5 | 6.93 | 6046x2947x3538 |
| 2YA1860 | 2 | 10.8 | 5~80 | 1800x6000 | 400 | 50~300 | 970 | 8 | 22 | 7.52 | 7011x2947x3471 |
| 3YA1860 | 3 | 10.8 | 5~80 | 1800x6000 | 400 | 50~350 | 970 | 8 | 22 | 7.72 | 7243x2987x3955 |
| 4YA1860 | 4 | 10.8 | 5~80 | 1800x6000 | 400 | 50~350 | 970 | 8 | 22 | 8.70 | 7498x2987x4439 |
| 2YA2160 | 2 | 12.6 | 5~100 | 2100x6000 | 400 | 100~500 | 730 | 6~8 | 30 | 10.2 | 7076x3402x3666 |
| 3YA2160 | 3 | 12.6 | 5~100 | 2100x6000 | 400 | 100~500 | 730 | 6~8 | 30 | 10.5 | 7284x3467x4092 |
| 4YA2160 | 4 | 12.6 | 5~100 | 2100x6000 | 400 | 100~500 | 730 | 6~8 | 30 | 10.8 | 7551x3467x4582 |
| 2YA2460 | 2 | 14.4 | 5~150 | 2400x6000 | 400 | 150~700 | 730 | 6~8 | 37 | 10.4 | 7046x3770x3603 |
| 3YA2460 | 3 | 14.4 | 5~150 | 2400x6000 | 400 | 150~700 | 730 | 6~8 | 37 | 10.8 | 7289x3 |
What are the evaluation of the customers to our equipments?
- "We have decided to increase the purchasing of jaw crusher as it chases what it says is highly efficient and environmental friendly." - Client From Zimbabwe
- "Cooperating with SBM brings us more opportunities to maximize our production. Especially its jaw crusher and jaw crusher spare parts just match our plant." - Mr. Bruce Munro, Chief Executive Mining - Client From Australia
- "Dealing with SBM Machinery especially jaw crusher trading is the best choice since i started importing & exporting of mining equipment." - Clients From South Africa
- "The company is worth a win-win business of mining equipment after i was touched by their jaw crusher service." - Clients From India
Ways of Packing:
1.Sand blasting, coat with high quality paint;
2.Product wrap by PP-Bubble
3.Load container, Spear Parts in wooden case.
Transportation:
1. By sea Freight;
2. MSK/MSC/APL/EMC/WANHAI/KLINE
3. We will remind you before boat arrival
Shanghai Shibang Machinery Co., Ltd participate in various exhibitions frequently.
Such as Bauma China,China Import and Export Fair , Asia-pacific's International Mining Exhibition, Bauma Africa, CONEXPO Latin America , etc.
About SBM
SHANGHAI SHIBANG MACHINERY CO., LTD is one high-tech enterprise, which involves R&D, production, sales and service as well. In the past 20 years, we devote to producing mining equipments, sand making machines and industrial grinding mills, offering expressway, rail way and water conservancy projects the solution of making high grade sand and matched equipments.Till now, our products are sold to 130 countries, being the popular equipments in global crushing and grinding industry. Here all SBM machines are designed produced, assembled and texted according to the ISO9001:2008.
About SBM Factory
SBM (Shanghai shibang machinery Co.,Ltd) has three factories, the gross area is about 2.3 million square meters. Various world-class CNC are in these factories, such as CNC VTL OPERATOR, Planing Machine, CNC heavy-duty horizontal lathe. These advanced equipments ensure that our products are of precise specification. Also, we have professional Quality inspection division, every machines produced must be examined strictly, the quality is guaranteed.
Minimum Order Quantity
A: The minimum order quantity is 1 Set
Delivery time
A: The lead time is 10-30 days, Delivery time will vary depending on the type of the machine, shipping method selected and part availability.
FOB Prices
A: Different machine has different FOB price, please send your interest type, raw material, capacity, Your contact information, we will give you a reasonable FOB price as soon as possible
Payment terms
A: Accepted Payment Type: T/T, L/C, Western Union, Cash
After sign the contract, pay the 10%-30% deposit of total purchase price and pay the full payment before delivery.
Products warranty
A: The Products warranty is one year.
After we signed the purchase contract and have a certain reputation guarantee, we will contact the professional group that responsible for ship bookings, commodity inspection, commercial invoices, packing list, insurance policy and so on, in order to provide you the perfect goods trading services, until the product you purchased properly to your hands.
We will send a professional and high levels installation engineer team at the same time the product properly to the destination, in order to supply you a full range of products installation services. For some typical problems, our rigorous installed engineers also will do some certain installation debugging training, etc. Technological support SBM has been largely adopting new technologies, new techniques and high-tech equipments. And SBM also has strict and effective quality control system.
