Cargo truck is mainly designed for transporting goods and for business use. By its applications, it can be classified two types: general cargo truck and multi-purpose truck and the former can be divided in two parts: van and flatbed tow truck. And the latter is mainly used to carry cargo in terms or its design and structure, but there are folding seats or fixed seats behind the driver’s seat. Therefore, this truck could hold more than 3 passengers.
As a professional cargo truck supplier in China, we offer a wide range of products that includes compressed garbage truck, tractor truck, water tank truck, and low plate semi-trailer, among others.
Key Characteristics:
High Safety
1. Four independent braking systems
Our cargo trucks adopt four direct-operated pneumatic braking systems (front axle brake, rear axle brake, parking emergency brake, engine auxiliary brake), with automatic clearance adjustment. This, coupled with modem brake devices like ABS, makes your driving highly reliable and safe.
2. Wide-angle rearview mirror
The luxury wide-angel rearview mirror provides the drive with unobstructed all-around visibility, further assuring driving safety.
Aesthetic Design
- Our cargo trucks are outlined with full and smooth lines, which better meets aerodynamic principles and greatly reduces the drag coefficient, thus significantly improving fuel economy.
- Luxury and stylish integral bumper, elegant high-brightness headlights.
- New soft interior and dashboard are both aesthetic and practical; detachable combination instrument is convenient to repair and maintain.
- Electric window regulator, central electric control door lock
Low Fuel consumption
- Low fuel consumption: 1200-1200 turn over wide economic speed low fuel consumption, a new combustion principle, the second generation of Bosch common rail fuel injection system, high economic benefit. sinotruk low price 6*4 cargo wagon lorry truck euro 2 made in china
| vehicle model | ZZ1311N4661W | |||
| Cab | Model | L2000 | ||
| Type | Extended cab ,single berth,up/down and front/back adjustable steering wheel,VDO instrument and control module,and safety belt with double locking mechanism,exterior sun visor | |||
| Engine(optional) | Model | WD615.87 290hp | WD615.69 336hp | WD615.47 371hp |
| Rated power,kw/rpm | 213/2200 | 247/2200 | 273/2200 | |
| Maximum torque,Nm/rpm | 1160/1100-1600 | 1350/1100-1600 | 1460/1100-1600 | |
| Displacement,L | 9.726 | |||
| Type | Inline 6 cylinder,2 valves,supercharged intercooling,rear supercharger | |||
| Clutch | Φ430Bdiaphragm spring clutch.Hydraulic control air power assisted.Standard 430A type for WD615.49 engine,Standard 430Btype for 615.69 engine,Standard 430C type for WD615.87 engine. | |||
| Transmission | SINOTRUK HW series 10 speed transmission,main and auxiliary transmission struct,main transmission with double countershaft,auxiliary transmission with planetary reducer.Standard HW15710 type for WD615.87 engine,standard HW19710 type for WD615.69and WD615.47 engine. | |||
| Front axle | HF9 drum-type,rated load of 9T | |||
| Drive axle | HC16 double reduction(central reduction+wheel reduction),speed ratio:5.73,4.8 | |||
| Suspension | Front and rear leaf spring suspension,front suspension with shock absorber and transverse stabilizer,rear suspension is disconnected type with transverse stabilizer | |||
| Steering system | ZF8098 steering gear,ZF steering oil pump,system pressure of 18Mpa | |||
| Brake system | Service brake:dual-circuit pneumatic brake;parking brake:energy storage spring air cutoff brake;auxiliary brake:engine exhaust brake.Standard engine EVB,and with ABS option automatic slack adjuster | |||
| Electrical system | Voltage:24V;generator:2240W;Starter:24V,7.5kw;battery:12V/165AH,2pieces | |||
| Tyre | 12.00R20;optional 12.00R24/12.00-24 | |||
| Tank volume,L | 400 | |||
| Kerb weight(vehicle/chassis),kg | 12500/10650 | |||
| Gross mass,kg | 31000 | |||
| Rated load,kg | 18370;Optional 18570 | |||
| Complete vehicle external dimensions(length*width*height),mm | 11894*2490*3205 | |||
| wheelbase,mm | 1800+4600+1350 | |||
| Front/rear overhang(vehicle/chassis),mm | 1320/(2824/2625) | |||
| Wheel track(front/rear),mm | 2041/1850 | |||
| Minimum ground clearance,mm | 314 | |||
| Approach/departure angle(vehicle/chassis) | 20.5/(10/14) | |||
| Maximum speed,km/h | 90 | |||
| Maximum climbing ability,% | 20 | |||
| Minimum turning diameter,m | 21.3 | |||
| Container inside dimensions(length×width×height)mm | 9600*2300*(800+1500) | |||
| Cotainer volume,m3 | 50.3 | |||
Zhongqi Group Jinan Kaogeer Special Truck Co., Ltd. and its holding company Jinan Haoruitong Special Truck Co., Ltd. (former Jinan Halle Automobile Manufacturing Co., Ltd.) are located in Jinan Industrial Development Park, that engaged in developing and manufacturing special truck and components, the modern professional enterprise is a public announcement management company of the Ministry of Industry and Information and is a major transportation equipment manufacturing enterprise in Jinan City.
The company mainly manufacturing the dump truck, concrete mixer truck, compression garbage truck, sewage suction truck, sprinkling car, powder material truck, municipal engineering vehicles, semi-trailers, new energy automobile, product ramified all over the country and Southeast Asia, Africa, North America, the Middle East, Russia and other markets.
The company has more than 10 years of special truck Research & Development and manufacturing experience, and fully absorbs the leading international technology and innovates independently, to establish the industry-leading system of technical innovation, product development, process development, manufacturing and quality assurance.
The company basis for technological innovation, market demand-oriented, customer-centric, supporting excellent team, to create the world famous special truck brand and build first-class truck manufacturing base.
The company continuous innovation and development, and constantly bring new products into the market, also innovates and manufacturing customized-design products. Sincerely welcome dealers and customers to contact with us and thanks for your patronage!
Pakage:Nud/waxing
Shipping tools: By RORO ships under the deck.
Shipping terms:FOB/CFR/CIF
Shipping terms:FOB/CFR/CIF
Payment conditions: 30% by T/T in advance, the balance shall be effected 7 working days before the shipment.
Delivery Period: within 30 working days after receiving advanced payment or letter of credit.
