Help CenterHowo A7 6*4 Dump Truck
Related Products
Specifications
Howo A7 6*4 Dump truck
Sinotruk dump truck
300hp,WD615engine,Eur3
All Hyva 150 hydraulic system
Front lifting
Howo A7 6*4 Dump truck
Sinotruk dump truck
300hp,WD615engine,Eur3
All Hyva 150 hydraulic system
Front lifting
Characteristic:
1. Howo A7 series heavy-duty truck has fine and splendide appearance, word top-class cabs, and brand-new power systerm.
2. Multiple security and reliability represent it's leading position in heay-duty truck industry in China.
3. The tank body uses the latest design concept, the whole body adopts the lightweight structure and streamlined design, and is made of pollution, and high safety.
4. Equipped with Hayward hydraulic systerm it is the latest product with the features of value for money and security and reliability in recent times.
Main TDS:
Model |
ZZ3257M3847N1/T1WA |
||
Condition |
New |
||
Drive type |
6×4 |
||
Steering Wheel Type |
LHD(Left hand drive) |
||
Fuel Type |
Diesel |
||
Engine |
Type |
SINOTRUK brand,WD615.97E EGR engine |
|
Emission standard |
EURO III |
||
Horse power |
300hp |
||
Maximum output |
220Kw @ 2200 rpm |
||
Displacement(L) |
9.726 |
||
Cabin |
A7-W with two seats, and one sleeper, 2-arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer, with 4-point support fully floating suspension + shock absorber |
||
Steering |
German ZF8098 hydraulic steering with power assistance |
||
Transmission |
Manual Type. HW19710 Sinotruk 10 Speed Transmission,10 forward and 2 reverse |
||
Clutch |
Ø430mm diaphragm spring clutch |
||
Front axle |
HF9(9 ton),rigid stubaxle with double T-cross section |
||
Driving axle |
[AC16] Heavy hub reduction drive axle |
||
Rim/Tires |
12.00R20 Radial tyre |
||
Wheel base(mm) |
3825+1350 |
||
Dimension of cargo body(mm) |
L×W×H |
5800×2300×1500 |
|
Thickness of steel plate |
Bottom: 8 Side: 6 |
||
Capacity |
20.01 CBM |
||
Overall Dimension(mm) |
8585×2496×3490 |
||
The total mass(Kg) |
25000 |
||
Kerb weight(kg) |
12300 |
||
Maximum speed (km/h) |
78 |
||
Fuel tank |
400L |
||
Color |
According to you |
||
