Place of Origin Guangdong, China
Brand Name Caijing
Model Number SCM162-10
Type COB

sunlight readable 16x2 lcd module support 3SPI or I2C serial interface with low power consumption

Product Description

Model no: CM162-10
Character format: 5x8 dots
Module dimensions: 84x44x12mm
Viewing display area: 64.6x13.8mm
Active display area: 54.84x11.14mm
Character size: 2.94x5.38mm
Character pitch: 3.46x5.76mm
Dot size: 0.54x0.62mm
Dot pitch: 0.06x0.06mm
Drive method: 1/16 duty, 1/5 Bias
Viewing O'clock: 6 O'clock
LED backlight color: white
LCD driver: AIP31068 controller

10880 bits CGROM,512 bits CGRAM

3SPI or IIC interfaces,5x8 dots matrix

sunlight readable 16x2 lcd module support 3SPI or I2C serial interface with low power consumptionsunlight readable 16x2 lcd module support 3SPI or I2C serial interface with low power consumption

Certifications

 Our factory pass ISO9001 and all products can pass CE,ROHS,SGS.



sunlight readable 16x2 lcd module support 3SPI or I2C serial interface with low power consumptionsunlight readable 16x2 lcd module support 3SPI or I2C serial interface with low power consumptionsunlight readable 16x2 lcd module support 3SPI or I2C serial interface with low power consumptionsunlight readable 16x2 lcd module support 3SPI or I2C serial interface with low power consumption





Company Advantages



14 year's design,manufacture and sales experience
300+ models available,custom orders welcome
exporting to 100+ countries
Free 1-year maintance

Free samples are available for some styles



Related Products

 About character lcd module ,we also have 16x1 character lcd module display ,16x2 character LCM,16x4 monochrome lcd display,20x2 lcd ,20x4 lcd display ,40x2 small size lcd module,40x4 lcd display module.



Display Content Model No. Outline Size(mm) V.A(mm) Dots Size Controller Voltage Interface
8x2 CM802-1 40×35×7 28×14 0.5×0.5 SPLC780 5V/3V serial/parallel
8x2 CM802-2 58×32×13.5 38×16 0.56×0.66 SPLC780 5V/3V serial/parallel
8x2 CM802-6 58×32×13.5 38×16 0.56×0.66 SPLC780 5V/3V serial/parallel
12x1 CM121-1 103×35×11 76×25 1×1.4 SPLC780 5V/3V serial/parallel
16x1 CM161-1 80×36×12 64×13.8 0.55×0.7 SPLC780 5V/3V serial/parallel
16x1 CM161-2 122×33×14 99×13 0.92×1.1 SPLC780 5V/3V serial/parallel
16x2 CM162-1 122×44×13.4 99×24 0.92×1.1 SPLC780 5V/3V serial/parallel
16x2 CM162-3 84×44×13.7 62×18 0.55×0.65 SPLC780 5V/3V serial/parallel
16x2 CM162-4 80×36×12 64×13.8 0.54×0.62 SPLC780 5V/3V serial/parallel
16x2 CM162-10 84×44×12 64×13.8 0.54×0.62 SPLC780 5V/3V serial/parallel
16x2 CM162-11 80×36×12.5 64.9×15.9 0.54×0.62 SPLC780 5V/3V serial/parallel
16x2 CM162-12 85×36×11.3 64.9×15.9 0.54×0.62 SPLC780 5V/3V serial/parallel
16x2 CM162-13 80×36×12.5 64.6×13.8 0.55×0.55 SPLC780 5V/3V serial/parallel
16x2 CM162-15 85×29×11.3 64.9×15.9 0.54×0.62 SPLC780 5V/3V serial/parallel
16x2 CM162-17 85×36×14 62×16 0.55×0.65 SPLC780 5V/3V serial/parallel
16x2 CM162-36 80x36x11.3 64.9x15.9 0.54x0.62 SPLC780 5V/3V serial/parallel
16x4 CM164-1 87×60×12.5 61.5×25 0.55×0.55 SPLC780 5V/3V serial/parallel
16x4 CM164-2 87×55×12.5 61.5×25 0.55×0.55 SPLC780 5V/3V serial/parallel
20x2 CM202-1 116×37×12.5 83×18.5 0.61×0.66 SPLC780 5V/3V serial/parallel
20x2 CM202-2 180×40×14.3 148×23 1.1×1.12 SPLC780 5V/3V serial/parallel
20x2 CM202-3 116×32.5×7.9 87.8×17.5 0.553×0.569 SPLC780 5V serial/parallel
20x2 CM9079 123×25×12.7 85×12.9 0.55×0.65 SPLC780 5V serial/parallel
20x4 CM204-1 98×60×14 76×26 0.55×0.55 SPLC780 5V/3V serial/parallel
20x4 CM204-2 146×62.5×13 123×42.5 0.92×1.1 SPLC780 5V/3V serial/parallel
40x2 CM402-1 182×33×11.5 154×15.8 0.6×0.65 SPLC780 5V serial/parallel
40x4 CM404-1 190×54×13.6 147×29.5 0.5×0.55 SPLC780x2 5V/3V serial/parallel
