Specifications
JHL5101GXW Sewage Suction Truck 4*2Capacity 3.1M3
Engine Power:70kw
Tank Capacity:3.1M3
Vane pump
JHL5101GXW Sewage Suction Truck 4*2
The introduction of Germany advanced manufacturing technology, with rinsing underground sewage pipes,the collection and transportation of sludge and city life waste and building operations such as muddy water in liquid waste and other functions.
Main specification:
No. |
Item |
Unit |
Value |
|
1 |
Model |
|
JHL5101GXW |
|
2 |
Chassis model |
|
EQ1108KJ |
|
3 |
Engine power |
KW |
140 |
|
4 |
Overall dimension of truck(L*W*H) |
mm |
6975*2462*2950 |
|
5 |
Overall dimension of tank(D*L) |
mm |
Ø1300*3870 |
|
6 |
Effective volume of tank |
m3 |
5 |
|
7 |
Front overhang |
mm |
1205 |
|
8 |
Rear overhang |
mm |
1802 |
|
9 |
Max speed |
km/h |
90 |
|
10 |
Vehicle curb weight |
kg |
6440 |
|
11 |
Vehicle gross weight |
kg |
10500 |
|
12 |
Diameter of suction tube |
mm |
Ø100mm |
|
13 |
Suction depth |
m |
≥ 8 |
|
14 |
Opening angle of the rear tank door |
° |
60 |
|
15 |
Tank lift angle |
° |
30 |
|
Vacuum |
Type |
|
Vane pump |
|
Pumping speed |
m3/h |
310 |
||
Rated speed |
rpm |
1300 |
||
Max vacuum |
Absolute value |
|
10 |
|
Percentage |
% |
90 |
||
