Curtis Series Controllers are available in a wide range of models, from simple analog controllers to sophisticated, microprocessor based controllers with CANbus communications and comprehensive diagnostics.
Curtis Models 1204M provide fully programmable control of DC series motors performing on-vehicle traction or pump duties. These microprocessor-based MOSFET controllers add flexibility and versatility to the time-proven Curtis series motor controller family.
Primarily designed for battery-powered vehicle applications using either electric or hydrostatic traction. These include industrial trucks, personnel carriers, mobile elevating work platforms, and golf and utility vehicles.
1204M/1205M
| Vehicle Type | Golf/Utility |
| Application | Traction or Pump |
| Max Voltage [VDC] | 72 |
| Armature Current (2 min) [A] | 275 - 500 |
| Plug Braking | Option |
| Programmable Parameters | Yes |
| Line Contactor Driver | Option |
| CANbus | No |
| IP Rating | IP 54 |
Unit: mm
Model |
Voltage (V) |
Current Limit(A) 5 Sec Boost 2 Min 1 Hour |
||
1204M-42XX |
24/36 |
303 |
275 |
125 |
1204M-53XX |
36/48 |
358 |
325 |
140 |
1204M-63XX |
48/72 |
358 |
325 |
140 |
