Specifications
JHL5258GJB Concrete mixer truckconcrete truck mixer 14CBM
6*4,375Hp
Eaton pump
Bonfiglioli, PMP reducer
JHL5258GJB Concrete mixer truck
concrete truck mixer 14CBM
6*4,375Hp
Eaton pump
Bonfiglioli, PMP reducer
Using foreign advanced technology and after over ten years of technological improvements, now the products has become more perfect in performances, more reliable in quality, and more convenient in operation.
1. Feature one: The tank body uses double helical blades that makes its density moderate, with symmetrical mixing board on the front taper place; double blades and guiding blades
of discharge are installed on the outlet of tank, which makes the discharge more evenly, faster in speed, and convenient for the pumping transportation of other devices (such as
automobile pump).
2. Feature two: The tank body adopts the domestic first submerged arc welding technology which makes it more solid in strength and more beautiful in appearance. The linked parts of
the tank body use bounded construction which can extend its service life. The seal head adopts German cold spinning technology that makes it sleek and fine in appearance. And
six reinforcement plates are installed inside the seal head and can increase its wear resistance.
3. Feature three: Low angle for mixing drum can extend the service life of hydraulic pump, motor and reducer. The sub frame uses high intensity square tube with damping in the central
area that can play role when vehicle is at full load and under the bad conditions of road, which can lower the center of gravity of truck and make it move more smoothly.
4. Feature four: The blades are extruded by more than 20 sets of molds, which can ensure the spiral curve and angle and spiral distance, and can achieve uniform mixing of concrete.
5. The upload production of this mixer adopts multiple advanced technology, which can produce various types of mixer in volume such as 8m3, 9m3, 10m3, 12m3, 14m3, 16m3and so on.
|
14CBM Dongfeng CONCRETE MIXER TRUCK JHL5258GJB |
|
|
Chassis model |
DFL3251A8 |
|
Max. running speed(km/h) |
90,102 |
|
Drive System |
6×4 |
|
Kerb weight(kg) |
15600 |
|
Total mass(kg) |
25000 |
|
Overall dimensions (mm) |
Length |
9900 |
Width |
2500 |
|
Height |
3998 |
|
Capability (CBM) |
14 |
|
Wheel base (mm) |
4300+1350 |
|
Overhang (mm) (F/R) |
1500/2240,1500/2215 |
|
Track width (mm) (F/R) |
2040/ 1850 |
|
Engine |
dCi375-30 Diesel engine Euro3 |
|
Rated output horsepower |
375 hp |
|
Gearbox |
Manual Type, Fastre RT11509C |
|
Steering |
hydraulic steering with power assistance |
|
Cab |
D310-S1 |
|
Axle |
7000/18000 (Double axle co-load) |
|
Tire(RADIAL TYRE) |
11.00-20,11.00R20, 12.00-20,12.00R20 |
|
Tilt angle |
10° |
|
Rotating speed |
0-16rpm |
|
Water tank capacity |
400L |
|
Residual rate of discharge |
<0.5% |
|
Max. dimension of hopper(mm) |
980 |
|
