Why do you need to buy repeater/booster ?
Unfortunately,there are still no signal in some places,for example:
-Parking lots,tunnels
-Big store
-Car,boats,office building
-House in remote area
How can repeater bring your mobile phone better signal?
| MODEL: | ICS10-WCDMA |
| Frequency range | WCDMA(uplink:1920~1980mhz;Downlink:2110~2170mhz) |
| Gain | 45±3dB |
| Automatic Level Control | >= 60dB |
| NF | <= 5dB |
| Gain Flatness | <= 2dB/3.84MHz |
| Automatic Gain Control | 30dB in step of 1dB (Auto) |
| Output Power | UL >= 10±2dBm DL >= 10±2dBm |
| Output Power | <= -25 dBm |
| Input intermodulation | Comply with 3GPP TS 25.106 |
| Output intermodulation | Comply with 3GPP TS 25.106 |
| Frequency stability | <= 0.01ppm |
| ACPR | 45dBc/30KHz@±5MHz & ±10MHz |
| Spurious Emission Mask | Comply with 3GPP TS 25.106 |
| Spurious Emission | Comply with 3GPP TS 25.106 |
| Modulation Accuracy | <= 12.5% |
| Peak Code Domain Error | <= -35dB @ Spreadimg Factor 256 |
| Group Delay | UL<= 1μs |
| Dimension | 240mm×160mm×50mm |
| weight | <= 1Kg |
| power | AC220V / DC 5V <= 350 mA |
| Working environment temperature | -10~55°C |
How should you install repeater (very easy and simple):
Step 1: Use your mobile photo to test signal strength outside house or on roof, -70dbm is the basic requirement (full bar).
Step 2 Install outdoor antenna in that location and keep adjusting, point it to signal tower station, try to get best signal.
Step3: Run outdoor coaxial cable into building in a convenient location to connect with signal repeater.
step 4: Mount your indoor antenna with signal repeater
step5: Power up signal repeater device to check the signal inside, moving outdoor antenna until you get satisfied signal.
Note: Connect outdoor ANT (BTS) port with outdoor antenna, connect indoor ANT(MS) port with indoor antenna, outdoor antenna is mounted at a higher position. Both antennas should be 10 meters far away from each other at least.
Indoor and outdoor antenna must be separated by wall.
After sale service
We have two years quality warranty for all customers,you can return goods to us when you receive defective repeater,but freight charges should be responsible by buyer.
Signal problem & installation technique supporting
1.If still weak signal receipt after installation, please check if outdoor antenna point to signal tower correctly or elsewhere has stronger signal and confirm signal strength achieve-70DBM.
2.If still have no signal after installation, please check our device power adapter whether connected perfectly? And connectors connect well.
3. If strength is not steady, please check if outdoor and indoor antenna is too close; please ensure outdoor antenna has distance of 10 meters at least, with a barrier and not in a same horizontal line.
4. Packed the outdoor connector by waterproof glue, otherwise wet reduce the signal cover area.
