Home > Electrical & Electronics > Telecommunication & Broadcasting > Repeater > Factory Wholesale High Gain 900 1800 Wireless Bosster Gsm Repeater
Factory Wholesale High Gain 900 1800 Wireless Bosster Gsm Repeater
US$ 10 - 75
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
lintratek
Model Number:
KW20A-LTE gsm repeater
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fashionable Wireless Signal Expander,cell Phone Amplifier,wifi Repeater Outdoor/indoor Quality ChoiceUS$ 1 - 78.5MOQ: 50 Pieces -
Indoor Large Square Meters Coverage Area Cell Phone Repeater Vhf/uhf RepeaterUS$ 1 - 78.5MOQ: 50 Pieces
-
Hot New Products Power Repetidor 4G Signal Cellular Wifi Repeater ExtenderUS$ 1 - 78.5MOQ: 50 Pieces
-
Home New Design Cheap LTE Repeater,4G Signal Booster Car LTE Signal RepeaterUS$ 1 - 78.5MOQ: 50 Pieces
-
Factory OEM Wireless Wifi Extender System 2g/3g/4g Signal Booster/repeaterUS$ 10 - 122MOQ: 5 Pieces
Place of Origin
Guangdong, China
Brand Name
lintratek
Model Number
KW20A-LTE gsm repeater
factory wholesale high gain 900 1800 wireless bosster gsm repeater
Product Description
| Model No | KW20A-LTE gsm repeater | ||
| Parameter data | Uplink | Downlink | |
| Frequency Range | 2500-2570 MHz | 2620-2690 MHz | |
| Output Power | 17 ±2dBm | 20±2dBm | |
| Gain | 65 dB | 65 dB | |
| Bandwidth | Wide Band | ||
| Automatic Gain Control | >20dB | ||
| Ripple in Band | ≤5dB | ||
| Intermodulation Products | 9KHz~1GHz | ≤ -36 dBm | |
| 1GHz~12.75GHz | ≤ -30 dBm | ||
| Spurious Emission | 9KHz~1GHz | ≤ -36 dBm | |
| 1GHz~12.75GHz | ≤ -30 dBm | ||
| Noise Figure @ max. gain | ≤ 6 dB | ||
| VSWR | ≤3 | ||
| MTBF | >50000 hours | ||
| Power Supply | AC:90~265V, 50/ 60Hz;DC:12V 3A | ||
| Power Consumption | < 20W | ||
| Impedance | 50 ohm | ||
| Mechanical Specification | |||
| RF Connector | N-Female | ||
| Cooling | Heatsink Convection cooling | ||
| Dimensions (D x W xH ) | 140*95*30mm | ||
| Weight | 0.7kg | ||
| Installation Type | Wall Installation | ||
| Environment Conditions | IP40 | ||
| Humidity | < 90% | ||
| Operating Temperature | -10°C ~ 55°C | ||
Why do you need to buy repeater/booster?
Installation
How should you install repeater (very easy and simple):
Neutral full kit
A regular cell phone repeater consists of (full kit)
- 1 -Outdoor antenna log periodic antenna(or wall mounted, yagi antenna)
- 2 - Indoor Omni ceiling antenna( panel antenna)
- 3 – Power adapter
- 4 - User manual
- 5 - Cell phone repeater
- 6. 10 meters outdoor cable and 5 meter indoor cable
Product Uses
Company Information
Certifications
Our Services
Trade Shows
FAQ:
Signal problem & installation technique supporting:
1.If still weak signal receipt after installation, please check if outdoor antenna point to signal tower correctly or elsewhere has stronger signal and confirm signal strength achieve-70DBM.
2.If still have no signal after installation, please check our device power adapter whether connected perfectly? And connectors connect well.
3. If strength is not steady, please check if outdoor and indoor antenna is too close; please ensure outdoor antenna has distance of 10 meters at least, with a barrier and not in a same horizontal line.
4. Packed the outdoor connector by waterproof glue, otherwise wet reduce the signal cover area.
