LINTRATEK New design pico repeater 1900MHz PCS brands repeater

LINTRATEK New design pico repeater 1900MHz PCS brands repeater

Specification Details

•

  Model No		KW20A-PCS
  Parameter data		Uplink	Downlink
  Frequency Range		1850-1910  MHz	1930-1990  MHz
  Output Power		17 ±2dBm	20±2dBm
  Gain		65 dB	65 dB
  Bandwidth		Wide Band
  Automatic Gain Control		>20dB
  Ripple in Band		≤5dB
  Intermodulation Products	9KHz~1GHz	≤ -36 dBm
  	1GHz~12.75GHz	≤ -30 dBm
  Spurious Emission	9KHz~1GHz	≤ -36 dBm
  	1GHz~12.75GHz	≤ -30 dBm
  Noise Figure @ max. gain		≤ 6 dB
  VSWR		≤3
  MTBF		>50000 hours
  Power Supply		AC:90~265V, 50/ 60Hz;DC:12V 3A
  Power Consumption		< 20W
  Impedance		50 ohm
  Mechanical Specification
  RF Connector		N-Female
  Cooling		Heatsink Convection cooling
  Dimensions (D x W xH )		140*95*30mm
  Weight		0.7kg
  Installation Type		Wall Installation
  Environment Conditions		IP40
  Humidity		< 90%
  Operating Temperature		-10°C ~ 55°C
