Specifications
1,COB led down light2, Power: 20W
3, 2 years warranty
4, AC 100-240V
5, 120Degree
[Product Features]
1. Ra (color rendering index) is 70 - 80, strong restoring authenticity when irradiating objects.
2. With wide voltage constant current design (AC85 - 265), and wide application.
3. Continuous light work, the temperature within 50 °
4 Be able to light continuously 1000H, brightness, illuminance and luminous flux are zero attenuation.
5.Service life is above 30.000 hours, energy saving, environmental protection, power consumption is only 10% - 20% of incandescent lamp.
6. It is the green light source, no UV or IR radiation, no harmful elements, facilitate recycling and reusing
[Cautions]
1. Do not clean the lamp with gasoline or chemical reagents;
2. Do not use it in high tempaerature or damp environment;
3. Cut off the power before dismantling or replacing;
4. Ensure that the product have 75mm vents around, can not violate the relevant fire regulations, the location where need to illuminate must away from the front of light at least 1000mm.
5. Lamps must not be covered by insulated pad or similar material.
Parameter
| Model | wattage | voltage | size | lifespan | led type&quantity | material | color temp | IP grade | lumen |
| WS-LYD005 | 3w | AC110AC240 | 90mm*55 | >50000h | EPSMD3528 | Aluminum | 2700k-7000k | 44 | |
| WS-LYD006 | 7w | AC110AC240 | 130mm*66 | >50000h | EPSMD3258 | Aluminum | 2700k-7000k | 44 | |
| WS-LYD007 | 9w | AC110AC240 | 160mm*72 | >50000h | EPSMD3528 | Aluminum | 2700k-7000k | 44 | |
| WS-LYD008 | 12w | AC110AC240 | 180mm*78 | >50000h | EPSMD3528 | Aluminum | 2700k-7000k | 44 | |
| WS-LYD009 | 18w | AC110AC240 | 190mm*80 | >50000h | EPSMD3528 | Aluminum | 2700k-7000k | 44 | |
| WS-LYD010 | 24w | AC110AC240 | 230mm*8 | >50000h | EPSMD3528 | Aluminum | 2700k-7000k | 44 |
Aluminum
