Our series of HDMI converters, switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient, more comfortable, more productive and more cost-efficient.
The HDMICAT30RX&TX Extender use double cat-5E or cat-6(recommended) cables up to 60 meters instead of HDMI cable to transmit high definition signal, for cutting down cost. Long distance transmission of high definition is very difficult because HDMI cable is very expensive and infrequent. The Extender is designed to supply for long distance transmission of high definition signal.
Our hdmi extender over ip 30M offer solutions for noise, space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.
l Support 3D
l Support video input : 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
l Signal transmission :Double cat-5e or cat-6(recommended) cables up to 30 meters instead
of HDMI cables are connected between TX and RX Extender.
l Support video output : 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
l Support CEC
l Audio format support : DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
l LED indication: when power is supplied or device is working, LED relative to is light.
l Support up to 30 metres AWG26 cable length between extender and source & sink device
l No loss of quality
l Installs in minutes
l Need DC5V/1A power supply
Length of CAT-6 cable between Rx and TX…..……………….……………..Up to 30 meters
HDMI Input…..…………………...………24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support audio format input..………DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
HDMI Output…..…………….…...………24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support audio format output...……. …………………………LPCM7.1/DTS/Dolby-AC3/DSD
Max bandwidth……………………………………………………………………………165MHz
Max baud rate……………….…….………………….………….………………………4.95Gbps
Input Video signal ………….…………………………..…………………….… 0.5~1.5Volts p-p
Output DDC signal ……………………………………………………………… 5Volts p-p (TT1L)
Input/Output HDMI cable distance………….……………..≤20m AWG26 HDMI standard cable
Max working current………………………………………………………………………...800mA
Power adapter format………...………Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
Operating Temperature range……..…………….………………………………… (-15 to +55℃)
Operating Humidity range………………………….….……….5 to 90%RH (No Condensation)
Dimension (L x W x H) ……………………………….…………………………81X45X25 (mm)
Weight…..………………………………………………………..………………………………246g
Shipping:
1. UPS / DHL / FEDEX /EMS / TNT and so on express(door to door)
2. For Air Shipment, Please choose your favorite, shipping method according your detail requirement
3. The shipping discount is different in different seasons and depend different weight, we will choose the cheapest and safest way according your detail quantities
4. Normally, it will take around 3-7days from China to destination country. Please note that some remote place will need 1-3 days more.
Delivery:
1. Sample within 1-3 days
2. Wholesales Orders : 5-7 days according various quantities
3. OEM 10-12 days after receiving your sample confirmation and payment.
Warranty:
1. One year warranty.
2. Please send back the defective goods which are within the warranty period, we will repair them or send you new one for free.
3. If it is the sample or only few pcs accessories (the fee is less or around shipping fee) are damaged, please send us some pictures and video about it need to confirm your problem, then we will send you free new goods instead.
