Load Cell,Load Cells,Single Point Type , CZL642
US$ 5.30 - 5.30
MOQ: 300 Pieces
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
TOP SENSOR
Model Number:
CZL642
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Load Cell, Load Cells,Platform Scale Load Cells,Table Top Scale Load Cells, CZL601US$ 2.00 - 2.00MOQ: 1000 Pieces -
Load Cell, Load Cells,Platform Scale Load Cells,Table Top Scale Load Cells, SPA-01ACUS$ 2.80 - 2.80MOQ: 1000 Pieces
-
Load Cell ,Single Shear Beam Type,Alloy Steel Load Cell,High Quality Load CellUS$ 11.50 - 11.50MOQ: 12 Pieces
-
Polished Glazed Tile Marble DesignUS$ 5 - 30MOQ: 300 Square Meters
-
Glazed Polished Tile 2US$ 23 - 30MOQ: 300 Square Meters
Place of Origin
China
Brand Name
TOP SENSOR
Model Number
CZL642
Load Cell,Single Point Type
CAPACITY:
100~500(kg)
FEATURES:
Aluminum-alloy; Colourless anodized; Hermetically sealed with glue to IP65.
APPLICATIONS:
Electronic counting scales, platform scales etc
WIRING SCHEME:
Red + |
(Input +) |
White - |
(Output -) |
Black - |
(Input -) |
Green + |
(Output +) |
It uses 4-core shielded cable (φ4×420mm). The length of the cable can be adjusted according to clients' request, but we suggest to use this standard length to ensure the output precision.
DIMENSIONS(mm):
Size: 150x40x40
PARAMETERS:
| Precision: 0.02%F.S | Insulation resistance: ≥5000MΩ(100VDC) |
| Rated output: 2±0.1mV/V | Excitation voltage: 9VDC~12VDC |
| Non-linearity: 0.02%F.S | Compensated temp.range: -10℃~+40℃ |
| Hysteresis: 0.02%F.S | Use temp.range: -20℃~+60℃ |
| Repeatariy: 0.02%F.S | Temp.effect on zero: 0.03%F.S/10℃ |
| Creep: 0.02%F.S/10min | Temp.effect on span: 0.02%F.S/10℃ |
| Zero balance: ±1%F.S | Safe overload: 120% |
| Input resistance: 405±10Ω | Ultimate overload: 150% |
| Output resistance: 350±3Ω | Defense class: IP65 |
