infrared touch panel screen protector fixed device

Specifications

fix film machine
1,fix film on screen of mobile phones,digital products
2,high precision,high efficiency
3,save more costs





Key Features:
1,The machine is special research and development for sticking the protective film,explosion-proof film, polarizing film with hign precision on mobile phone screen, tablet PC, car navigation etc.

2,Adopting photoelectric sensor and servo motor to achieve XY direction high precision automatic proofreading, to ensure that the sticking process location accuracy.

3,Using the unique mechanism to achieve no bubbles.

4,The machine Mainly includes PLC, servo motor, precision mechanical hand, sticking film mechanism, feeding mechanism,material receiving mechanism, human-machine interface, FFU filtering devices and other components, has been widely used in flat panel display industry.





Technical Specifications:



The efficiency of sticking	10~20pcs/min
Sticking accuracy	± 0.05mm
Range of sticking size	2.5~5.0 inches
Correction methods	XY correction
Stick results	smooth,without folds,no bubble
Work cleanliness	class 100 and high efficiency FFU (optional)
Working voltage	AC220V/50Hz
Gas supply pressure	≥ 0.4Mpa
Weight	about 450Kg
Machine dimension	950(L)*850(W)*1720(H)mm





Main performance:



1, using the PLC program and the high precision servo system control, reliable operation, stable performance, high precision position control.



2, the clear and intuitive interface, easy human-computer dialogue mode, convenient for various models of the settings and change.



3, laminating roller pressure is reliable, and with high precision micrometer tracking confirmation.



4, the machine adopts SMC pneumatic components and delta high precision servo control system.



5, equipment with high precision servo motor cross correction, to ensure the accuracy of the location of the glass.



6, the main components imported aluminum alloy, precision machining, grinding processing, ensuring the hardness and smoothness.



7, equipment mainly uses the Japan Keyence sensor and Germany the Leuze ultrasonic sensor.



8, equipment with automatic feeding and automatic film tearing blanking function.







Main advantages:





1, An automatic sticking film machine equipped with a worker for placing and recovering the panel, it can replace about six workers in production, greatly enhance the efficiency.





2,The automatic sticking film machine covers an area of less than 1 square meters, while it benefits to the manufacturers's clean room management and maintenance.





3, The automatic sticking film machines mechanization operation, to ensure that the sticking film process is stable, quality assurance and stability, to avoid the manual sticking film quality is not stable.





4, The automatic sticking film machine adopts imported advanced important precision parts, stable operation, no vibration, to ensure that the automatic sticking film with high location accuracy, a whole day can maintain high stability operation.





5, The automatic sticking machine adopts imported PLC control, touch screen human-machine interface, parameter setting through simple and intuitive, easy operation.





6, The automatic sticking machine is once purchased, correct operation and proper maintenance can be used more than five years.





7, The automatic sticking film machine adopts the high requirements of Japan, Germany, Taiwan and other well-known brands of spare parts production and assembly, based on the film factory process saves the manpower cost, management cost, building cost, and improve production efficiency, greatly improve the quality of the product, and enhance customer market competitiveness.
