Automatic wire stripping machine wire cutting and stripping machine;
Automatic wire stripping machine wire cutting and stripping machine Specification:
Item |
Parameters |
Model |
CWDM-6 |
Power source |
AC 220V/ 50/60Hz |
Dimension(L*W*H) |
600*480*450 |
Display |
Chinese + English |
Weight |
40 (KG) |
Power |
400(W) |
Cutting length |
1~29999mm |
Cutting tolerance |
(0.2±0.002×L)mm |
Stripping depth |
Adjustable |
Stripping length |
0-30mm on the wire head 0-30mm on the wire tail |
Middle Stripping times |
12 |
Wire cross section |
0.03-6mm² (Diameter0.6~5.0mm) |
Wires suitable |
PVC/BVR/ Teflon /Silica gel wires |
Blade material |
High-speed steel |
Drive mode |
4 wheels |
Automatic wire stripping machine wire cutting and stripping machine Features:
Ø Cutting wires;
Ø One end or both ends stripping or half-stripping, middle stripping;
Ø Fully automatic machine;
Ø Suitable for mass production and low volume diversified production;
Ø Producing of different size wires is simplified by changing different guiding tube
Ø With memory function, facilitate system settings.
Ø English control panel available.
utomatic wire stripping machine
Automatic Multifuctional Computer Wire Stripping Machine Spare Parts:
Blades and wheels are vulnerable parts, one spare part for each item is provided.
Automatic Multifuctional Computer Wire Stripping Machine Spare Parts:
Guarantee will be 12 months after delivery
Automatic Multifuctional Computer Wire Stripping Machine CE certificate:utomatic wire stripping machine automatic wire stripping machine
utomatic wire stripping machine automatic wire stripping machine
