mobile phone cover laser printing machine
Sepcification:
| CCD | F-130F series industrial camera |
| lens | Computar EX2C |
| laser head | import from japan |
| guide rail | TBI import grinding leadscrew X,Y two each, X450mm,Y520mm |
| servo motor | A5 motor series |
| I/O control card | ADLINK PCI-9074 |
| motion control card | ADLINK PCI-9074 |
| adapter card | BOXIN-BO1 |
| Static Eliminator | STATIC-ST401A series |
| Industrial control host | Industrial control host( RMC-8404/6113LP4/300ATX/8651VNA/P4/2.8G 2CPU(S)/1G DDR/80G/CD-ROM) |
| Display | DEL liquid crystal LCD17" displayer and Logitech mouse/Duble Swallow mo |
| ftware | |
| control system | WINdowsxp |
| operation interface | GUI |
| program | online |
| visual system | Pixel computational precision CCD visual orientation correction system(Independent R&D) |
| control software | F1.0.2 official |
| Dimension | 600mm*600mm*1180mm |
| weight | 100kg |
| Foot adjustable height | 60~110mm |
| Operation Monitors | |
| tri-color light | High brightness trichromatic lamp monitoring machine of all kinds of working condition |
| The motor overheat detection | Overheating, overload, low voltage protection function |
| Servo overload detection | With overload, circuit is normal and low voltage protection function |
| print counter | pcb type, print numbers,diverse counting way. |
| Machine error record | software automatic memory machine all alarm record |
| Accuracy | |
| Laser head position accuracy | 0.01mm |
| print precision | 0.01mm |
| Safety | |
| scope of work protector | Use all-direction seal protection way |
| door interlock protection sensors | Before and after the safety door safety switch induction(optional) |
| Manipulator | |
| motor type | Panasonic A5 motor series |
| control motor repeat accuracy | 0.01mm |
| The axis maximum working range | 400mm*400mm |
| Work station | |
| transmitt | Workbench automatic feeder,leadscrew transmission |
| max size | 400mm*400mm |
| edit mode | online programming |
| Program storage | select the storage location According to the need |
| collocate program CCD | computar Series high pixel color CCD |
operating principle:
Core principle: sensors detect the product after, back to the signal to the labeling control system, the signal after the PLC
processing, at the appropriate time to send out the tag attached to the product set position, product flows through the device,
tags coating is firm, a label attached
Features:
1.Configuring high-pixel CCD zoom lens, an auxiliary program Teach-camera editing function, higher precision and more accurate,
clearer images. Easy to edit & modify block programs and single-step program.
2.Intelligent control, automatic correction MARK point positioning systems, mobile real-time display and analog path trace route,
display a glance, automatic alignment correction, higher labeling accuracy.
3.Simple adjustment, adjust label position freely for 10 setting positions. It is simple to change different PCBs to save time.
4.Flexible application can pick off the production or assembly line production, production site layout is simple.
5.Powerful, has fault alarm function, production counting function, parameter setting protection function, convenient production
and management.
6.Transparent cover design, emergency button could avoid accident to ensure safe operating.
Characteristics:
1.The machine conforms to the IEC standard, the complete closed to complete a homework assignment, availability
2.Using two-dimensional platform and visual inspect system instantly take, arbitrary coordinate movement to realize high speed
automatic code.Code were varied, qr code, one-dimension code, can be Numbers, letters, special symbols, etc.
3.17 inch computer monitor, operator could observe the PCB print status at any time.Includes loader and unloader machine, realize
automatic PCB labeling, could print QR code, one-dimensional code, numbers, letters, special symbols and other species.
Labeling processng:
step 1. pick up labels according to points
Step 2. CCD correction Angle according to label position
step 3. label to the correct position
Our partners:
Our service processing:
