New lead 30-500TPD power saving sunflower oil making machine with ISO for sale
Solvent extraction is a process to extract oil from oil bearing materials by means of solvent, and the typical solvent is hexane. The vegetable oil extraction plant is part of vegetable oil processing plant which is designed to extract oil directly from oil seeds containing less than 20% oil, like soybeans, after flaking. Or it extracts oil from pre-pressed or fully pressed cake of seeds containing more than 20% oil, like sunflowers, peanuts, cotton seed and a variety of other materials.
Main machines
Tube condenser, oil stripper, solvent evaporator, desolventizer toaster, loop type Oil extractor, rotary or rotocel extractor, oil tank, etc.
Technology of the sunflower oil making machine
1.Absorbing the world’s leading core extraction technology, design and develop a process which is efficient, economical and reliable. Adopting box-chained loop type extractor can effectively achieve low residual oil, low solvent consumption and low failure rate of equipment. Thus, customers will have little cost and investment, and profit maximization will be achieved.
2.Full automatic computer control system is adopted in extracting process, adjust automatically and operate stably.
3.Negative pressure technology is adopted in condensate system. Using the secondary steam which comes from the DTDC as the heat source of first evaporation, thus can maximum save the energy consumption.
4.Stainless steel heat exchange tubes and multi-stage baffling make the condenser have a high heat transfer efficiency, also the water consumption is low.
5.Composed of pre-extraction, extraction and draining sections. There is material turnover in the process of extraction to make the extraction uniform and thorough. Special self-cell solvent spraying ensures the best effect during extraction.
The flow chart of oil extraction machine
Process details of the sunflower oil extraction machine:
1. Extracting process of sunflower oil making machine
The pre-pressed cake or flake, firstly enters into the seal auger to avoid the solvent gas escaping. Then material enter into the box-chained loop type extractor and counter-currenting with the solvent, the grease is extracted, and miscella concentration increases from 2% to more than 25%. Then miscella is discharged from extractor, and into miscella filter for filtration. After separating fines, miscella enter into the oil tank, then pump into evaporation system. And the leached meal finally drops in DTDC through buried scraper plate.
2. Evaporation process of sunflower oil extraction machine
Using the secondary steam desolventized from DTC desolventizer and produced by steam-jet pump to heat and evaporate micella in the first long-tube evaporator. Export temperature reaches to 58-62℃ and concentration reaches to more than 65%. Then, micella enters into the second long-tube evaporator in which the temperature is heated to 105-110℃ by indirect steam and the concentration reaches to more than 95%. Then miscella enters into stripper in which residual solvent in oil will be removed, the export temperature reaches to about 105℃ and the general volatile of the extracted crude oil is less than 0.30%.
3.Desolventizing process of sunflower oil machine
Wet meals discharged from the bottom of extractor enter the top of DTDC and land on the predesolventizing trayers where they are heated by the indirect steam, thus, some solvent in meal is evaporated and meal temperature is risen; Predesolventized meals land on predesolventizing trayers where they use the second steam in desolventizing trayers to predesolventize solvent from meal, then, meals enter desolventizing layers in which direct steam is injected. Direct steam is sprayed into the meals through the bottom holes, and distill the solvent from meal by using steam in order to remove all solvent; Desolventized meals land on the following drying and cooling layer to dry and cool meals,cooled meals land on meal scraper blade from automatic material controlling gate on the bottom of cooling layer, and then they are entered into meal storehouse.
4. Condensation recovery of sunflower oil making machine
DTDC is equiped with a separate condenser, 1st and 2nd evaporation share one condenser. Low and high temperature of solvent gas both from 1st and 2nd evaporation enter into the condenser after its neutralization, which greatly reduces the load of condenser and improves the efficiency of condensing. Stripping and analyzing share one condenser, the non-condensable gases from extractor and other condensers enter into the vent gas recovery system through the final condenser.
In the recycling system, the cold paraffin will absorb the solvent gas and the final nonsolvent gas will be discharged through fire resistance valve.Paraffin absorbed the solvent gas can be also called rich oil, after heating by oil-oil heat exchanger and steam, the rich oil will enter into desorber for desorption, and into condenser after changing solvent into gas, the final cooled paraffin can be recycled.
1. Simple in structure with stable performance;
2. Evaporation takes place in a vacuum for the best oil quality.
3. Extraction system can process different raw materials.
4. High efficient solvent recovery system.
5. With full energy conservation and repeat utilization, steam consumption is markedly reduced.
6. Composed of pre-extraction, extraction and draining sections.
Residual oil in meal |
≤1% (soybean) |
Solvent consumption |
≤3Kg/T (6#solvent oil) |
Crude oil moisture and volatile matter |
≤ 0.30% |
Power consumption |
≤ 15KWh/T |
Steam consumption |
≤280Kg/T (0.8MPa) |
meal moisture |
≤ 10-13% (adjustable) |
Residual solvent in meal |
≤300PPM (qualified detonated experiment) |
Zhengzhou New Lead Grain and Oil Science and Technology Co., Ltd.
Advantages:
1. Specializing in edible oil processing plants and its machines, like oil pre-treatment plant, oil solvent extraction plant and oil refinery plant.
2. Providing you first-class technology and service to ensure the project being completed smoothly.
3. Over 150 personnel, professionals take up more than 30%.
4. Passing the quality management system certification of ISO9001-2000.
5. Offering tailor-made turnkey solutions to the client's right from designing and erection to commissioning and maintenance.
Business Scope
10-2000t/d vegetable oil pre-pressing and extraction plant;
10-600t/d vegetable oil refinery plant;
10-300t/d animal oil refinery plant;
50-500t/d aroma peanut oil production line;
3000-10000t/y soybean protein isolates production line;
10000-30000t/y production line of soybean protein concentrate, textured protein;
Production line of oil dewaxing, fractionation and winterization;
Production line of glycerin and fatty acid;
Production line of biology diesel oil.
The company offers tailor-made turnkey solutions to the client’s right from designing and erection to commissioning and maintenance.
We will provide the owner first-class technology and service to ensure the project being completed smoothly.
If you are interested in our products or have any questions, please do not hesitate to contact us! We are always at your service!
