PCB Separator machine
Sepcification for LED Light Bar Separator
| Separation speed | 100-220 mm/s |
| Cutting length | 100 mm -unlimited |
| Cutting thickness | 0.8-3.5mm |
| Cutting width | 8-225 mm |
| Number of blades | max 9 pairs |
| Voltage | 110/220V |
| pcb separator Machine size | 1155 x 405x330mm |
| pcb separator Machine weight | 70 KG |
| Length of platform | 1150 mm (customized ) |
Features for pcb separator machine :
1,9 pairs of blades is available ,the number of blades cab be customized .
2,Configuration of the blades is adjusted toindividual PCB
3,Sensors are used to monitor the separating process
4,The PCBs are placed either by hand or they feed automatically
by a loading station.
5,Easy operating
6,Could be adjusted according to PCB sizes and customers'
requirements
7,Could be customized made as customers' request
Detail images for pcb cutting machine :
Package : plywood case
Chuangwei Electronic Equipment Manufactory limited specilizes in provision of peripheral SMT service and equipments .including pcb separator ,pcb depaneling machine, pcb cutting machine , CNC router ,solder pot, hot bar soldering machine ,screwing machine and glue dispensing machine . Chuangwei Prosses an experienced professional team and equipements with leading technology to provide first class product and service to the companies home and overseas.
With the corporation spirits of "hardworking, sincere, devoted, cooperative and innovative", we have won the customer`s trust and satisfaction with excellent quality and efficient professional service, which is further quaranteed by ISO9001:2000 quality management system and get CE certificate .
We expect a sincere and extensive cooperation with the customers to explore a beautiful future together
