Help CenterPress Fit Fixture In Pcb Assembly
US$ 1 - 500
MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
Chuangwei Press Fit Fixture
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen / hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Duronstone Wave Solder Pallets for Reflow SolderingUS$ 1 - 555MOQ: 1 Set -
Wave Solder Pallets and Reflow Soldering Pallets With Black Durostone MaterialUS$ 1 - 500MOQ: 1 Set
-
Wave Solder Pallers Made of DurostoneUS$ 1 - 333MOQ: 1 Set
-
SMT Tooling Solder Pallet and FixtureUS$ 1 - 500MOQ: 1 Set
-
Auto Soldering MachineUS$ 5,500 - 6,500MOQ: 1 Set
Condition
New
Place of Origin
Guangdong, China
Brand Name
Chuangwei Press Fit Fixture
Model Number
CWZJ-12
Voltage
220V
Power(W)
1400W
Weight
55
Dimension(L*W*H)
1200 x 2400
Certification
CE ISO9001
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Selective Wave Soldering Pallets are used to apply TH components to printed circuit boards during PCB assembly.
The pallets are made of a glass epoxy insulated material. They protect the SMT components in the circuit and expose the unmasked components to wave soldering.
Wave Solder Pallets significantly streamline the circuit assembly process, eliminating the need for extensive manpower and manual labor.
Steps In the Manufacturing Process:
- The customer’s files and a complex card are received (the original files that were prepared by the circuit editor).
- The Planning Department opens the pallet files and inspects the card.
- Detailed pallet files are prepared, including all the slots, dimensions, thickness, and areas that require masking of sensitive parts.
- The files are sent to the customer for approval
- Customer approval is received, and the files are handed over for production
- The raw material is milled
- The palette is assembled by adding elements such as: clamps, buttons and bridges.
- The pallet is manufactured and a full inspection is carried out.
Employing a similar process to wave solder pallets production, Chuangwei also produces jigs, trays, reballing devices, pallets for conformal coating, and devices for press-fit.
