Home > Products > water proof metal shell connectors > Electrical connector
Electrical connector
- 5000 Piece / Pieces per Month
- SHANGHAI
- Credit Card
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | kp | Model Number: | AISG |
Type: | DIN | Application: | Microwave | Gender: | Male |
Product Description
Specifications
Electrical connector,AISG connector 8 pin , screw coupling,can interchange with Amphenol C 091 A /B/D,Binder's 423 seriesElectrical connector,DIN45326 connectors,AISG connector 6 pin ,The connectors of series FS1 are available with 3-8 contacts, screw coupling,can interchange with Amphenol C 091 A /B/D & Binder 423 series.Meet DIN45326 standard. All connectors of series FS1 are EMI protected and IP 67 proof. Main applications for FS1 connectors are industrial controls, data processing, instrumentation, medical devices, telecommunication network and equipment, plus outdoor and marine application.Cable connector main applications for 3G, Tower Mounted Amplifier, Base Stations.It is same as lumber 0332-1,0306-1,0307-1,and binder 680series,423 series.
Product Ordering
FS1 - 6 T J - 81 2 3 4 5
1.Name FS1 type connector
2.Number of contacts 3,4,5,6,7,8 pcs
3.Connector type: T:Plug; Z:receptacle
4.Contacts type: J:pin; K:socket
5.Meet cable diameter: 6-9 mm
Technical characteristicsTemperature | Relative humidity | Vibration | Shock | Endurance |
-55°C~ +85°C | 90-95% at 40 Deg C | 10~1000Hz 196m/s² | 490m/s² | 1000 cycles |
Contact | Current | Voltage | Contacts resistance |
1.5mm | 7 A | 60-220VAC | ≤3mΩ |
Contact Us
- Hangzhou Kaipu Electronic Technique Co., Ltd.
- Contact nameLIMING JIN
- Phone86-571-85386101
- AddressNo.588-2 of Feijiatang Road,3nd floor,Xiacheng science Park. Hangzhou,Zhejiang
