Help CenterRectangular Connectors F48 Series
Related Products
F series rectangular connectors incorporate the lasest design features and provide the assurance of high quality and reliability.Its technical characteristics and dimensional drawings meet the requirements of IEC603-F and DIN41612.The type of terminations include wrap,solder,cable,crimp.They have a wide range of application and interchangeable with connectors of foreign brand in the same category.We can match your special requirement by changing the number of contacts and the type of termination.Products ordering
F 48 -- M S L
1 2 3 4 5
1.Name of product: F series
2.Number of contacts : 348
3. Mmale connector,Ffemale connector
4.Ssolder,Wwrap,Ysolder lugs
5. Lwith cable,without Lwithout cable
Technical characteristics
Temperature |
Relative humidity |
Atmosphere |
Vibration |
Shock |
-55°C~ +125°C |
(90~95)% at40+2°C |
101KPa~6.7Pa |
5~500Hz 100m/s² |
10~40strokes/min 250m/s² |
Current |
Voltage |
Contact resistance |
Endurabce |
4A |
300V |
≤8mΩ |
500 cycles |
Environment |
Voltage proof |
Insulation resistance |
Normal |
2000V |
≥1000MΩ |
High temperature |
500V |
≥500MΩ |
Moisture |
500V |
≥50MΩ |
Low pressure |
200V |
- |
