electrical connector

Specifications

electrical connector ,small metal push pull ,small size,light weight,nice appearance,push pull self-lock connectors.

electrical connector small metal push pull Y5A series small connectors has the features of small size,lightweight,nice appearance, push-pull self-latching connecting system,mated simply and reliability,suitable for high-density.They are widely used for connection between sensors,electrical instruments and equipments.Product Ordering

Y5A  4   Z

  1    2   3

1.Product name:      Y5A series small connectors

2.Number of contacts:1, 2,3,4,5,6,7,8,9,10,12,14,16,18,19,22,30

3.Type:            T: plug,  Z: receptacle

Technical characteristics

Temperature	Relative humidity	Atmosphere pressure	Vibration	Shock
-55°C~+100°C	at40+2°C92~98%	1KPa	10~2000Hz,150m/s²	392m/s²



Contacts, current	Voltage	Contact resistance	Endurance
0.9mm3A	150V(2 contacts)	≤8mΩ	500 cycles
(0.7mm)1A	120V(4)	≤10mΩ
(0.5mm)0.5A	60V(6)	≤15mΩ
