Hige Speed Milk Tea Wrapping Machine
Features:
1. Be controlled by double transducer, flexible cutting and setting of bag length, time and film savable.
2. Human-machine operation, convenient and quick parameter seting.
3. Self diagnosis of failure function, clear failure display.
4. High sensitivity photoelectric eye tracking color mark and digital input of cut position make the sealing and cutting more accurate.
5. Separate PID control temperature, suitable for various packing materials.
6. Stopping the machine in the selected position, no sticking to the knife and no waste packing film.
7. Simple driving system, reliable working and convenient maintenance.
8. All the controls are achieved by software, convenient for function adjusting and upgrading.
Application:
Suitable for packaging soft, strip and unorganized objects like towels, chocolate bar, tissues, noodles,
egg rolls, sausages, sleeve-fish, Popsicle, soft candies, biscuits, fresh fruits, vegetable, mushroom, milk tea etc.
Model |
FB590/210 |
Max film Width |
590mm |
Packing speed (pack/min) |
50-100 |
Size of package |
L:100-400mm W:50-200mm H:50-140mm |
Dimension (L*W*H) |
4750*1105*1750mm |
The material of package |
OPP/PE PT AL/PE OPP/PE |
Overall weight |
1200kg |
Power Consumption |
220VAC 50HZ 3.66kw |
Conveyor length |
3m |
The PACK machine electric parts configuration list:
Item |
Name |
Brand |
Model |
|
1 |
PLC |
Delta |
DVP24ES200T |
China |
2 |
Servo Motor |
Delta |
ECMA-C20807RS |
China |
3 |
Servo Driver |
Delta |
ASD-B2-0721-B |
China |
4 |
Frequency Converter |
Delta |
VFD015EL21A |
China |
5 |
Touch Screen |
WEINVIEW |
TK6070IK |
China |
6 |
Residual Current Circuit Breaker |
FUJI |
EW32AAG-2P/32A |
Japan |
7 |
Temperature Controller |
TOKY |
AI-208 |
China |
8 |
Solid State Relay |
FOTEK |
SS-210DA |
TAIWAN |
As for the PLC and other electric parts configuration, we can use japan or Germany parts. But the price will be raised.
The PACKAGE MACHINE accessory spare parts list:
No. |
English Name |
Qty |
1. |
TOOL BOX |
1 |
2 |
HAMMER |
1 |
3 |
PLIERS |
1 |
4 |
CROSSHEAD SCREWDRIVER |
1 |
5 |
SHARP-NOSED SCREWDRIVER |
1 |
6 |
O-SHAPE TAPE |
1 |
7 |
O-SHAPE TAPE |
1 |
8 |
COPPER WIRE BRUSH |
1 |
9 |
INTERNAL HEXAGONAL WRENCH |
1 |
10 |
RETAINER PLIERS FOR HOLES |
1 |
11 |
RETAINER PLIERS FOR AXLES |
1 |
12 |
FORK WRENCH8-10 |
1 |
13 |
FORK WRENCH 12-14 |
1 |
14 |
FORK WRENCH 17-19 |
1 |
15 |
HEATING TUBE |
4 |
16 |
THERMOCOUPLE |
1 |
17 |
CARBON BRUSH |
4 |
18 |
FINGER |
6 |
19 |
FORK SHAFT |
6 |
20 |
SPLIT PIN |
10 |
21 |
CHAINED BUCKLE(08B) |
1 |
22 |
SEMI-CHAINED BUCKLE(08B) |
1 |
23 |
PRINTING CARTRIGE |
6 |
24 |
COPPER SHEET |
1 |
25 |
HEATING DISC |
2 |
26 |
COPPER ROD |
1 |
27 |
SOLID-STATE RELAY |
1 |
The upper parts and tool is accompany with the machine delivery to client.
FH2400 Heat Shrink Tunnel
Application:
FH2400 Heat Shrink Tunnel is suitable for packing of beverage, foodstuff, cupped instant noodles, juice, and milk tea and so on.
Features:
FH2400 Heat Shrink Packing Machine is suitable for heating-shrinking film package which features are transparent,
beautiful, dampproof and anticorrosive. FH Heat Shrink Tunnel have two temperature zones and hot wind circulation,
it can achieve good effect. It is widely for packing of beverage, foodstuff, cupped instant noodles, juice, and milk tea and so on.
This machine is suitable for PVC/POF/OPP/PE shrinkage film.
Preferences:
Model: FH2400
Packing Speed: Adjustable
Machine Dimension: 2400*600*1650 mm
Inner Size: 300*200*2000 mm
Types of film: PVC, POF, OPP, PE, etc.
Gross Weight: 400 kg
Power Required: 380V/AC, 3 phases, 50Hz 16kw
Milke Tea Sachet Wrapping Machine
