Help CenterAuto Paper Boxing Machine
Related Products
Specifications
Auto Paper Boxing Machine is used for inserting soaps, shoe polish, ointment, glass bottles, paper tissues automatically.Auto Paper Boxing Machine
1. Introduction:
This machine is high technology product incorporates of pneumatic-photo-electro-mechanic. It is suitable for inserting soaps, tubes, ointment, glass bottle, cosmetic and soft package ( packed condoms) into carton in a range. The machine finishes running by a series of photo-electro controller to make the machine stability and guarantee the packing quality. It includes folds leaflet automatic folding, carton suction and open, products and leaflet put into, printing batch number, sealing carton with tuck-in or hot melt glue device. The machine can be single used or linked with filling machine, blister packing machine, shrink machine, three-dimensional packaging machine etc to form a production chains.
2. Technical Data
Weight & Dimensions
Type |
FY120G |
Dimensions in mm |
1200×1250×1500 (L×W×H) |
Weight in kg |
1200 |
Output & Speed
Steady production speed |
80-100 cartons/min |
3. Utilities
Standard power supply |
220V – 50Hz |
Power consumption in KW |
2.6 |
Air consumption |
5-20L/min |
Compressed Air Pressure |
0.6MPa |
Noise |
<70 dB |
We have the most professional technology ( more than 20 years ) and the most serious attitude for our packing machines.
