Home > Auto, Motorcycle Parts & Accessories > Auto Parts > Axles > Semi Trailer Axle 10t 12t 13t 14t 15t 16t

Semi Trailer Axle 10t 12t 13t 14t 15t 16t

US$ 545 - 600 MOQ: 10 Pieces

Key Specifications

Get Latest Price

Type:

Axle Housing

Material:

Iron

Truck Model:

Other, all

Contact Supplier Request Quote Chat Now

Liangshan Changzai Machinery Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Type Axle Housing

Material Iron

Truck Model Other, all

OEM No. 123456

Place of Origin Shandong, China

Brand Name CZ

Model Number Germany type

Capacity : 12T,14T,16T
Stud : 10*M22*1.5ISO
Axle beam:150mm
Track:1840,1850mm
semi trailer rear axle

Model

105 (km/h) Max. Capacity (kg)

"S" Cam Brake Seriesφ x Width (mm)

Track TR (mm)

Spring Seat Installation LM (mm)

Axle Beam (mm)

Center distance of chamber GM (mm)

Studs (mm)

P.C.D. (mm)

φ H (mm)

Total Length LP (mm)

Recommended Wheel

Weight (kg)

Note

CZ2023

10,500

S 420×180

1820

≤435

()127

368

10xM22x1.5 ISO

335

281

~2165

7.50V-20

~363

(Outer) HM518410/45 (Inner) HM518410/45

CZ2024

10,500

S 420×180

1820

≤435

() 127

368

10xM20x1.5 JAP

285.75

221

~2165

7.50V-20

~359

CZ2026

10,500

S 420×180

1820

≤435

() 127

368

10xM22x1.5 ISO

285.75

220.1

~2165

7.50V-20

~356

CZ2423

13,000

S 420×180

1840

≤455

[]150

390

10xM22x1.5 ISO

335

281

~2185

7.50V-20

~368

(Outer) HM518410/45 (Inner) HM518410/45

CZ2424

13,000

S 420×180

1840

≤455

[]150

390

10xM20x1.5 JAP

285.75

221

~2185

7.50V-20

~363

CZ2426

13,000

S 420×180

1840

≤455

[]150

390

10xM22x1.5 ISO

335

221

~2185

7.50V-20

~361

CZ2023 AD

15,000

S 420×180

1850

≤455

()127

396

10xM22x1.5 ISO

335

281

~2185

8.00V-20

~398

(Outer) HM518410/45(Inner) HM220110/49

CZ2423 AD

15,000

S 420×180

1850

≤455

[]150

396

10xM22x1.5 ISO

335

281

~2185

8.00V-20

~383

CZ2062 BII

16,000

S 420×220

1850

≤455

() 127

354

10xM22x1.5 ISO

335

281

~2185

8.00V-20

~423

CZ2462 BII

16,000

S 420×220

1850

≤455

[]150

354

10xM22x1.5 ISO

335

281

~2205

8.00V-20

~425

CZ2482 BII

20,000

S 420×220

1850

≤455

[]150

354

10xM24x1.5 ISO

335

281

~2270

8.50V

semi trailer rear axle

trailer parts

CHANGZAI AXLE FEATURES:

1.BEAM: use 20Mn2 seamless pipe, through onepiece press forging and special heatreatment,

which has great over loading capacity and high intensity.

2.HUB: can assembly ECO Hub system.

3.HEART TREATMENT:special heart-treated,low-alloy steel axle beam,offer more stability,greater capacity and lightr weight..

4.ABS :easy for ABS installation.

5.HUB CAP:New 100%tight fit hub cap with additional o ring,provide optimum.

6.SPINDLE:Solid inserted spindle and bearing journals laser heat treated,provide superior fatigue capability,the bearing position is processed by the method of hardening operation,therefore,the bearing can be fixed by hand instead of heating,also convenient for maintain and fixing.

7.BRAKE LINING:has high performane,non-asbestos,non-pollution,and long using life,For easy checking and replacing,it also comes with the position of the exhausting to remind customer to check and maintain.

8.BEARING:is adopted with the domestic top brand bearing,with the advangages of over loading capability,high rotating speed,good intensity,abrade resistant and heat reststant.

9.PROCESS:use double side single hole boring lathe and double side three hole boring lathe,which process the both sides of axle body at same time to insure the axle concentric.

10.BOLT:are made of alloy material,which has the capability of high intensity,well streth&bends intensity.

11.GREASE:use internation famous brand grease,which can provide high lubricating performance and protect bearing well.

14t bpw 10 bolts trailer parts

material

1.Axle beam material:20Mn2

2.Brake drum:QT450

3.Hub:HT250

4.BRAKE CHAMBER:Q235

5.AXLE HEAD:20MN2

6.SELF-LOCKING NUT:40Cr

7.SELF-LOCKING BOLT:35m10x15

8.WASHER:35CrMn
