Trailer Axles 10t 13t 14t 15t 16t
| Axle Type | Max.Capa-city(T) | Track(mm) | Brake(mm) | Centre Distance of Spring Seat | Axle beam | Centre Distance of Brake Chamber | Stud | P.C.D(mm) | Hole Diameter(mm) | Total Length(mm) | Recommended Wheel | Axle Weight(kg) | Bearing |
| CZ10-20 | 10.5 | 1820 | 420*180 | 950 | Φ127 | 368 | 10*M20*1.5 | 285.75 | 221 | 2165 | 7.5V-20 | 347 | HM518445/10 HM518445/10 |
| CZ10-20A | 10.5 | 1820 | 420*180 | 950 | Φ127 | 368 | 10*M22*1.5 | 335 | 281 | 2165 | 7.5V-20 | 360 | |
| CZ13-40 | 13 | 1840 | 420*180 | 930 | Φ150 | 388 | 10*M20*1.5 | 285.75 | 221 | 2185 | 7.5V-20 | 350 | |
| CZ13-40A | 13 | 1840 | 420*180 | 930 | Φ150 | 388 | 10*M22*1.5 | 335 | 281 | 2185 | 7.5V-20 | 365 | |
| CZ15-50A | 15 | 1850 | 420*180 | 940 | Φ150 | 396 | 10*M22*1.5 | 335 | 281 | 2185 | 7.5V-20 | 385 | HM220149/10 HM518445/10 |
| CZ16-50A | 16 | 1850 | 420*220 | 940 | Φ127 | 354 | 10*M22*1.5 | 335 | 281 | 2185 | 8.00V-20 | 421 | |
| CZ16-50B | 16 | 1850 | 420*220 | 940 | Φ150 | 354 | 10*M22*1.5 | 335 | 281 | 2185 | 8.00V-20 | 425 |
