Latest Sawdust Stick Making Machine With Various Diameter
Introduction of the Sawdust Stick Making Machine
♥Our new Sawdust Stick Making Machine has a great improve in quality and capacity, which will prolong the working lives. The Sawdust Stick Making Machine press can be used to extrude charcoal bar in different shape as hexagon, cylinder or quadrangle under high pressure and high temperature.
♥We don’t need to add anything into the sawdust, only the sawdust will be ok.
♥This new type Sawdust Stick Making Machine has advantages of: Good performance, high production capacity and density, low power consumption, and wear. The final product also has high heat, no pollution, and longer burning time,
♥The shape of the charcoal can be plate, square, roll, triangle, cone etc. We can also customize the shape according to your requirement,
Structure of the Sawdust Stick Making Machine
1 hopper
2 heat insulation cover
3 heating circle
4 propellers
5 heating tube
6 taper sleeve
7 stents inner sleeve
8 stents
Material of the Sawdust Stick Making Machine
wood sawdust, waste sawdust, cotton stalk, coconut shell, rice husk, cotton stalk, bean stalk and other biomass material.
Material requirements for the Sawdust Stick Making Machine
1. The ideal size was identified to be 3-5mm wood sawdust
2. Moisture Ideal level was 8%-12 %.
3.Wood sawdust ,wood waste, rice husk, leaves, coconut shell, peanut shell and so on.
Application of Sawdust Stick Making Machine
1. Machine made charcoals are widely used for family to get warm.
2. These charcoals are with large demands for barbecue international markets
3. It can display the coal and heavy oil to burn steam boiler in industry.
4. The charcoals can be chemical raw material to deep process activated carbon, carborundum, crystal silicon and so on.
Parameters of Sawdust Stick Making Machine
Model |
Power (kw) |
Capacity (kg/h) |
Packaging size (m) |
Gross weight (kg) |
Net weight (kg) |
ALC-NC50 |
15 |
160-200 |
1.7*0.66*1.5 |
600 |
500 |
ALC-NC80 |
18.5 |
250-300 |
1.9*0.8*1.8 |
750 |
680 |
ALC-NC80B |
22 |
300-400 |
2.1*0.8*1.8 |
960 |
900 |
Raw material for Sawdust Stick Making Machine
Photos of the Sawdust Stick Making Machine
Payment terms:T/T;Western Union;Money Gram;Escrow,100% LC;Credit Card
Transportation: By sea, By air; Express(DHL/FedEx; Railway; Highway)
Packaging: Strong wooden case as exported standard
Delivery: 5-7 days for the charcoal making machine
FAQ
Q: Raw material for the Sawdust Stick Making Machine?
A: All kinds of biomass waste, such as crop straw, wood sawdust, coconut shell , rice hull, bamboo sawdust, peanut shell, sunflowers shell, cotton stalks, sesame straw, furfural dregs, corn cob and shrubs broken branches, etc
Q: Requirements about the raw materal?
A: Ideal size should be 1-5mm, ideal moisture should be 8%-12%
Q: Conversion rate betwenn the material and charcoal?
A: Per Kilogram sawdust can make 0.4kg charcoal,
Q: what kind capacity do you have?
A: 150-200kg/h; 250-300kg/h; 300-400kg/h; 1Ton/h etc
Q: The diameter of the briquette can be?
A: 50mm; 60mm; 70mm; 80mm
Q: Shape of the briquette can be?
A: Hexagon; Octagon; Quincunx; Square; Triangle; Square
Why us?
1, Manufacturer and factory, more than 10 years experience, professional design, excellent quality!
2, Customize suitable machine as your requirement!
3, Product variety
4, Advanced technology and engineer
5, High working efficiency from inquiry to finish order: Fast delivery
6, Answering your hesitation and question in time
7, Overseas installation, commissioning; trainning
8, Long time guarantee:1-3 years
Company Introduction
Established in 2004, Zhengzhou Allance Trading Co., Ltd. is a professional manufacturer and exporter, which is concerned with the design, development and production of biomass machines especially on Charcoal Briquette Machines, Wood Pellet machines etc. All of our products comply with international quality standards and are greatly appreciated in a variety of markets around the world. As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching North America, Europe, South America, Asia and Africa.
If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future!
