Zhengzhou Allance Floating Fish Shrimp Feed Pellet Machine
I. Introduction for Floating Fish Shrimp Feed Pellet Machine
It is widely used for producing maize flour, soybean flour or compound powder, wheat bran into high grade aquatic feed pellets for fish, catfish, shrimps, dog,.cat etc. The puffing fish feed pellets can float on the water surface for over12 hours without water polution. According to your requirement and production scale, floating fish feed machine can be classified into dry type machine and wet type machine.
II. Working principle for Floating Fish Shrimp Feed Pellet Machine
After the material is sent into feeding device, they will be extruded and expanded by the screw shaft with high pressure and temperature which makes the raw material fully cooked and sterilized. Then the expanded material will be formed into pellets by shaping mould. You can change different moulds to make pellets with different diameters. After that a cutting device will cut the formed pellets into different length as required.
III.Features for Floating Fish Shrimp Feed Pellet Machine
1.According to different requirements, variety shapes of high-grade feed pellets for fish, shrimps .etc
2.The finished pellets can keep floating for 12 hours without pollution to water.
3.The floating time can be controlled by the puffing degree adjustment
4.Floating fish feed machine can make pellet from diameter 1mm-12mm just by changing the mould.
5.Electric heating device is adopted which can improve the feed expansion rate and pellets floating time.
6.High temperature and high pressure cooking process can kill the salmonellosis and bacterial infections and
also makes the pellets easily to digest.
7.The cutting device can be adjusted to make pellets of different length.
8.The wet type machine needs a boiler to make steam which can conduct steam to the conditioner and ripen the raw material in advance.
IV. Complete flow chart for Floating Fish Shrimp Feed Pellet Machine
Raw material preprocessing--crushing--mixing--extruder--cooler--dryer--flavoring
V. Technical datas for Floating Fish Shrimp Feed Pellet Machine
Dry type Floating Fish Shrimp Feed Pellet Machine
| Model | Capacity (t/h) | Main Motor Power(kw) | Screw Feeder Power(kw) | Screw Diameter(mm) | Cutter Power(kw) |
| DGP50 | 0.06-0.08 | 11 | 0.4 | φ50 | 0.4 |
| DGP60 | 0.12-0.15 | 15 | 0.4 | φ60 | 0.4 |
| DGP70 | 0.18-0.25 | 18.5 | 0.4 | φ70 | 0.4 |
| DGP80 | 0.3-0.35 | 22 | 0.4 | φ80 | 0.6 |
| DGP90 | 0.4-0.45 | 37 | 0.4 | φ90 | 1.5 |
| DGP120 | 0.5-0.7 | 55 | 0.4 | φ120 | 2.2 |
| DGP135 | 0.8-1.0 | 75 | 0.4 | φ133 | 2.2 |
| DGP160 | 1.2-1.5 | 90 | 0.75-1.1 | φ155 | 3.0 |
| DGP200 | 1.8-2.0 | 132 | 1.5 | φ195 | 3.0-4.0 |
Wet type Floating Fish Shrimp Feed Pellet Machine
| Model | Capacity(t/h) | Main Power(kw) | Feeding Power(kw) | Screw Diameter(mm) | Cutter Power(kw) | ConditionerPower(kw) |
| DSP60 | 0.18-0.20 | 15 | 0.4 | 60 | 0.4 | 0.37 |
| DSP70 | 0.30-0.35 | 18.5 | 0.75 | 70 | 0.4 | 1.1-1.5 |
| DSP80 | 0.40-0.45 | 22 | 0.75 | 80 | 1.5 | 1.5-2.2 |
| DSP90 | 0.50-0.55 | 37 | 1.1 | 90 | 2.2 | 2.2-3.0 |
| DSP120 | 0.7-0.8 | 55 | 1.1 | 120 | 2.2 | 2.2-3.0 |
| DSP135 | 1.0-1.2 | 75 | 1.5 | 135 | 3.0 | 3.0-4.0 |
| DSP160 | 1.8-2.0 | 90 | 2.2 | 155 | 3.0 | 4.0 |
| DSP200 | 3.0-5.0 | 132 | 2.2 | 195 | 4.0 | 5.5 |
Complete line for Floating Fish Shrimp Feed Pellet Machine
Popular final products for Floating Fish Shrimp Feed Pellet Machine
We are professional manufacturer for feed pellet machines with decades experience. Main machines have CE approval. We have exported widely to Southeast Asia, Africa, America market. Below are the pics for certificate and our delivered plants.
1. Professional solution design, high quality machines, competitive prie.
2. Consult and answer all your questions within 24 hours.
3. Factory layout design according to your requirement.
4. Formulation available.
5. Fast delivery:
15 working days for single machine
40 working days for complete line
6. Professional engineer, overseas installtion and commissioning, trainning.
7. Warranty: 3 years
8. Service life long technical support.
9. Payment: We accept TT, Western Union,L/C,Trade Assurance,etc.
Welcome to contact us for more details !
