5 gallon barrel water washing filling capping machine
Introduce
Host is consist of frame, water tank, pipe, pump, cylinder, transmission, electrical appliances and other parts ,which can complete the empty barrels of washing, filling, and capping. Through multi-channel flushing process, it can fill quantitatively and cap automatically. The whole process is controlled by computer, so it has stable flushing effect, accurate filling volume, and good sealing effect.
A complete set of production line is mainly composed of automatic pulling out covering machine, rotary brush barrels machines, automatic bucket machine, washing machine, normal pressure filling machine, conveying cap, washing cap, trimming cap, covering cap, intelligent steam heat shrinkable machine, on-line inspection, straight-line pail bagging machine and palletizing machine set, which is a whole continuous operation.
Charateristics
This machine structure is compact, covers a small area of factory building, processes high stable and reliable efficiency and high degree of automation, which is a mechanical, electrical and gas automatic equipment in the trinity.
Technical parameters
Model |
ALC5-100 |
ALC5-300 |
ALC5-600 |
ALC5-900 |
Filling station |
1 |
2 |
4 |
6 |
Applicable bottle range |
18.9L |
18.9L |
18.9L |
18.9L |
Production capacity(B/H) |
100 |
300 |
600 |
900 |
Airconsumption(m3/min) |
0.37 |
0.6 |
1 |
1.5 |
Main machine power(kw) |
1.38 |
3.8 |
7.5 |
9.75 |
Machine weight(kg) |
680 |
1500 |
3000 |
3500 |
Machine size(L*W*H m) |
0.5*4.0*1.5 |
0.9*4.0*1.5 |
1.8*4.0*1.5 |
2.4*4.0*1.5 |
Filling material |
Pure water, mineral water, etc |
|||
Filling method |
Atmospheric pressure filling(no leaking) |
|||
Sealing method |
Chaining capping |
|||
Why Choose Us
1. Over 10 years eperience.
2. TUV, BV international certificate.
3. Export to Italy, Spain, Slovakia, Yemen, etc. winning great popularity
4. One year warranty.
5. Fast, timely delivery & reliable after-sales service.
6. Spare parts & tools delivered with harvester for daily maintenance.
7. Customers & quality first
Transportation
sea transportation, air transportation, railway transportation, highway transportation, express transportation
Acceptable payment
T/T, Escrow, L/C, Western Union,Moneygram,etc
If you are interested in our machine, pls feel freee to contact me!!!
