Wireless GSM module home intrusion alarm system with delay function--YL-007M3B

Specifications

1.GSM home alarm systems
2.adopt 900/1800/1900MHZ
3.Monitor environment on the spot.
4.Alarm delay function

Functions ;

1.Wireless GSM security home alarm systems ;

2.Monitor environment on the spot.
3. SMS Voice and alert.
4. Got CE/FCC/CCC certificate





Wireless GSM module home intruder alarm systems with the following functions :

1. GSM 900/1800/1900 bands, can be used all over the world.
2. Full duplex communication with the base.
3. Monitor environment on the spot.
4. Voice and message alert.
5. Set alarm ON or OFF by remote controller.
6. Call in to set alarm ON, OFF, Monitor, Output.
7. Send SMS to set alarm ON, OFF, Monitor, Output.
8. 5 group phone + room number.
9. 1 group alarm monitor center phone.
10. 2 group phone to report alarm and non-alarm status.
11. Can program 7 group alarm messages.
12. 3 zones for wired detector.
13. 16 zones for wireless detector.
14. Easily set ON or OFF for every wire or wireless detector.
15. 1 relay output to power on camera when alarm.



Technical specifications:

Static current:50mA
Power:9V-12V DC
Working temperature:-20°C~+85°C
GSM900/1800/1900MHz
Receiving code: ASK
Frequency:315/433 MHz
wireless distance: 100 m
wireless detectors:16
wire detectors:3

Standard Kits :



1 main panel,

1 wireless infrared (motion) detector,

1 wireless door magnetic detector,

1 siren,

2 remote controller ,

1 power
