XT-620 Series of Eye Drops Plug-putting, Cap-screwing and Filling Machines

XT-620 Series of Eye Drops Plug-putting, Cap-screwing and Filling Machines photo-1
XT-620 Series of Eye Drops Plug-putting, Cap-screwing and Filling Machines photo-2
XT-620 Series of Eye Drops Plug-putting, Cap-screwing and Filling Machines photo-3
XT-620 Series of Eye Drops Plug-putting, Cap-screwing and Filling Machines photo-4
XT-620 Series of Eye Drops Plug-putting, Cap-screwing and Filling Machines photo-5
XT-620 Series of Eye Drops Plug-putting, Cap-screwing and Filling Machines photo-6
US$ 1,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Chemical, Commodity, Food, Medical
Packaging Type:
Case
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai sea port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage, Chemical, Commodity, Food, Medical
Packaging Type Case
Packaging Material Wood
Automatic Grade Automatic
Driven Type Electric
Voltage 50HZ 2KW
Power 220V
Place of Origin Shanghai, China
Brand Name Xiaoteng
Model Number XT-620
Dimension(L*W*H) 2100mm*1350mm*1730mm
Weight 650kg
Certification ISO9001
After-sales Service Provided Engineers available to service machinery overseas











Product Description



XT-620 Series of Eye Drops Plug-putting, Cap-screwing and Filling Machines









XT-620 Series of Eye Drops Plug-putting, Cap-screwing and Filling Machines



Main performance and features





Applicable for filling round or unnormal shape bottles with capacity of 2-30 ml, such as eye drops, naristillae and auristillae or liquid split charging in scientific experiments, composition test and other fields.





Filling, putting inner plug, putting outer cap and screwing cap are performed with the use of high accuracy cam mechanism.





It is operated with touch screen; production speed can be set with programme. Filling accuracy is high and packing volumes can be adjusted conveniently with the use of imported peristaltic pump or ceramic pump. It has functions of non-filling with no bottles and automatic elimination.



Good safety barrier property; scientific design; impact structure; easy to operate.













Technical parameters







Applicable specifications

2-30ml

Speed

80-120 bottles/min.

Air consumption

1m3/h   0.3-0.4kg

Net weight

650kg

Power supply and total power

220V   50HZ   2KW

Boundary dimension

2100mm*1350mm*1730mm
