Ice maker machine
INTRODUCTION:
Supermarket flake ice machine, store flake ice machine, food preservation ice machine, APEX has long-term cooperation with lots of large domestic and overseas supermarket chains. The flake ice machine are efficient, energy saving, technology, and has good product quality assurance, service, with good public praise.
Small and medium commercial flake ice machine daily ice output: 350 kg / day ~3 tons / day.
SPECIFICATIONS:
Flake ice temperature: -5 ℃~8 ℃
Flake ice thickness: 1.8mm-2.5mm
Flake ice is a kind of dry and loose flaky ice. Compared with the small block ice, it has larger surface area than the other various shapes of ice in the same weight. It has larger surface area, and faster heat exchange process, could quickly melt into water, take away heat, increased the humidity of mixture, the cooling effect is better. It has a large ratio of surface area per unit, and is suitable for rapid cooling. Could enter the gap between the object to be cooled, reducing heat exchange, keeping the ice temperature, and at the same time have a good moisturizing effect.
DESION:
·Famous Refrigeration units, compressor and refrigeration accessories.
·Intelligent control systems, PLC automatic control the ice making unit to open and stop, so that ice cylinder operating system and water circulation system coordinated match, to achieve safe and efficient operation.
·Evaporator, using a number of independent national patents, and patent processing technology, ensure the core section of flake ice machine, evaporator, efficient heat transfer properties, good corrosion resistance, adapt new refrigerant energy saving, low-carbon economy requires.
·Safe and reliable, integrate advanced processing technology and Ice ideas and experience, equipment have features of resistant to high load, high reliability design, the evaporator pass CE standards European standard pressure vessel directive, storage of liquid or gas all ensure the human body safe.
· Ice skates blade, using spiral blade, low load, low resistance, low loss and no noise, the flake ice has uniform size, easy to produce powder.
APPLICATIONS:
Ice machine is suitable for cold storage, keep fresh of meat, food refrigerated, frozen aquatic products frozen, rapid cooling, marine, fish processing, food processing, fruit, vegetables, meat distribution, chemical industry and pharmaceutical industry etc.
MODELS:
Supermarket, store standard ice table is 1.8 * 0.9 m, if the ambient temperature is 20 ℃, daily ice loss between 90-150Kg /m2, if the temperature is higher, ice loss should be larger.
A standard ice table 1.8 * 0.9 m, if the ice countertops lay 5 ~ 6cm ice, you can choose a 350kg / day flake ice machine, consider the life of the machine, we recommend use of 500kg/ day of flake ice machine. If around the table marked with standard wall of ice, ice wall width 18cm height 15cm, you should use a 1 ton / day flake ice machine, the same consideration from the life of the machine, we recommend use of 1.5 tons/day, or 2 tons/day flake ice machine.
1.5T ice maker
GM-15K Flake ice machine | |||||
Model No. | Ice output (kg/24h) | Ice Storage (kg) | Ice product (kcal/h) | Evaporate Temp. (℃) | Total power (kw) |
GM-15K | 1500 | 400 | 8405 | -20℃ | 6.2 |
Power supply | Refrigerant | Cooling method | Dimension (mm) | Storage Cabinet Dimension (mm) | Weight(not include storage cabinet)kg |
3p/380v/50Hz | R404 | Fan cooling | 1410*980*946 | 1320*980*1200 | 322 |
Standard working conditions: ambient temperature 25℃, feed temperature 16℃, condensing temperature 40℃, APEX has right to change specifications without notice.
