Mini Backhoe for Tractor , Fit With PTO

Name: Mini Backhoe for Tractor , Fit With PTO
Brand: Hanwo
SKU: 102413455
Availability: InStock

US$ 1,799 - 2,699 MOQ: 1 Unit

Key Specifications

Condition:

New

Application:

farm working

Place of Origin:

Shandong, China

Weifang Baili Tractor Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application farm working

Place of Origin Shandong, China

Brand Name Hanwo

Model Number LW-07

Dimension(L*W*H) 2601x2000x2460

Weight 800kgs

Features new

Certification ISO, CCC,CE

Warranty within 12 months after slaes

After-sales Service Provided Overseas service center available

Specifications

Compact tractor backhoe with hydraulic pump and tank ,
fit with tractor PTO ,
moveable,

Model	HW-6 (LW-6)	HW-7 (LW-7)	HW-8 (LW-8)
Maximum Digging Depth	6'0"	7'0"	8'0"
A. Digging Depth (two foot flat bottom)	5'6"	6'6"	7'6"
B. Swing Arc	180 °	180 °	180 °
C. Loading Height (bucket at 60 ° )	5'0"	5'0"	5'10"
D. Reach from Center Line of Swing Pivot	8'6"	8'6"	9'6"
E. Transport Height (maximum)	4'11"	4'11"	5'9"
F. Bucket Rotation	180 °	180 °	180 °
G. Loading Reach (bucket at 60 ° )	3'2"	3'2"	3'7"
H. Transport Overhang	3'5"	3'5"	3'6"
I. Undercut	2'4"	2'4"	2'6"
J. Stabilizer Spread, down position	6'6"	6'6"	7'5"
K. Stabilizer Spread, up position	3'11"	3'11"	5'1"
Bucket Cylinder Digging Force	2450 lbs	2450 lbs	2840 lbs
Dipper stick Cylinder Digging Force	1250 lbs	1250 lbs	2005 lbs
Shipping Weight (less bucket)	586 lbs	654 lbs	875 lbs
Hydraulic Volume Requirements	4 to 5 GPM	4 to 5 GPM	5 to 6 GPM
Hydraulic Pressure Requirements	2250 psi	2250 psi	2250 psi
Recommended Tractor HP Requirements	20 - 30 HP	35 - 55 HP	60-90 HP
Specifications May Depending on Tractor Model and Subject to Change Without Notification.
Tractor Must Be Equipped with ROPS and Seat belt That will Provide Better Safety.
