B Est Tractor for Small Farm 35hp With 4WD

B Est Tractor for Small Farm 35hp With 4WD thumbnail-1
B Est Tractor for Small Farm 35hp With 4WD photo-1
US$ 3,200 - 4,600 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
2WD
Contact Supplier Request Quote Chat Now
Weifang Baili Tractor Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 2WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 25.7kw
Certificate Other, CCC
Brand Name Hanwo
Model Number TE354
Place of Origin Shandong, China
After-sales Service Provided Overseas service center available

Main technical specifications

B est tractor for small farm 35hp with 4WD

Model

HW204

HW254

HW304

HW354

HW404

Type

4×4 WD

Dimensions

of tractor

(mm)

















Length



2430



Width



1230



Height (to exhaust)



1070



Height (to Cabin Top)



Tread



Front Wheel

960

Rear Wheel

980

Wheel base

1473

Min. Ground Clearance

277

Min. Radius of

Turning(m)



One-side braking

2.4

No braking

2.8

Dry Mass(kg)

900

Engine









Model



JD295IT



JD2100IT/

LD385

LD3T30/

LD390

LD4L22BT



LD4L23BT



Type

Vertical, Water Cooled and 4-stroke

Rated Power(KW)

14.7

18.4

22.1

25.7

29.4

Fuel

Diesel

Fuel consumption (g/kW.h)

≤250

≤248

≤238

≤238

≤245

Rated Rev.(r/min)

2400

Walking & turning

System







Tire



Front tire

6.00-16

Rear tire

9.5-24(optional 8.3-24,11.2-24)

Connection between engine and clutch

Shaft connection



Clutch

Single Disc, Dry-Friction, Single Stage

Transmission Box

(4+1)×2 Mechanical Type

Steering

Mechanical or Hydraulic Type

Suspension Type

Post positioned Tri-point Suspension, Catalogue I

PTO





Type and Rev.(r/min)

Single speed non-independent type 720 or double speed Non-independent 540/1000

Spline Size(mm)

Post positioned I35 Rectangle Spline with 6 teeth(6×28.91×34.79×8.69)



Packaging & Shipping



As usual,we will deliver the goods within 20 days receive the deposit,but also depend on the order quantity.International exporting standard,  Nude package or according with customer's demand



Our Service :

 1. spare parts and service supplied ,6-24 months warranty for tractors and spare parts.

2..We have our own professional spare parts department. Provide us with  Products name, Brand name, Model No. then we could make  a quotations for you .

3. On time delivery.

4.Gurantee period: 24 months, If human factors damage,we will not offer compensation; If quality problems, we  can exchange the broken parts, but the shipping freight is by your charge.

5. After-sale -deparment offer 24 hours online service; If necessary, engineers available to service machinery overseas.

Our company:



1.20 years manufacturer.



2.We do OEM tractor for FOTON.



3.All of our engineers are from FOTON.





We are the manufacturer of the tractors, located in beautiful Weifang city, Shandong provinces. Our factory is with ISO certificate, with strict quality control from raw material to finish goods. They are exported more than 70 countries in the world ,and OEM for Foton and Changlin Tractors in China. Welcome your visiting....
