silver mirror acp design decorative wall mirror decorative broken mirror

Specifications

silver mirror acp design decorative wall mirror decorative broken mirror
1.flexible moq 2. 15 days delivery 3.over 60 colors

         silver mirror acp design decorative wall mirror decorative broken mirror



1.PRODUCT STRUCTURE:



2.PRODUCT DETAILS:



Alloy	1100(common),3003,5005
Facade Coating	PE Coating,PVDF Coating
Core Material	Recycle Plastic,Pure Plastic,Fire Rated,Unbroken(one/two direction)
Alu Thickness	0.08mm to 0.5mm(max)
Panel Thickness	3mm to 5mm(max)
Common Width	1220mm,1250mm,1500mm,1570mm(max)
Common Length	2440mm,3200mm,5000mm



3.OTHER PRODUCTS:





4.HOT SALE SPECIFICATIONS:



Market	Specificatons
Philippines	1220*2440*4*0.21mm PE/PVDF
Thailand	1220*2440*4*0.30mm PVDF
Ghana	1220*2440*4*0.40mm,0.50mm PVDF
Panama	1220*2440*4*0.21mm PVDF
Iraq	1250*3200*4*0.30mm PE
Poland	1500*5000*3*0.21mm PE Glossy/Matt color



5.APPLICATION



A.Interior Wall





B.Ceiling





C.Exterior Wall





7.PROCESSING



1) Saw Cutting



It can be easily processed with wood product processing saw and plate saw.

It's recommended to use hard alloy blade.



2) Slotting



It's important to make the U type slotting process with a distance 0.2 to 0.4mm from the polyethylene substrate,recommended slot angle is 110.



A.Milling machine and trimmer.Running speed:20000-30000rpm Feed speed:3-5m/min



B.When processing large quantity of U type slots,it's recommended to use round saw and belt saw.

flakeouter diameter:305mm number of teeth:24 running speed:3,000-5,000 rpm



 3) Bending with panel folder



If operated on the platform,bending part can be made very tidy.Platen puncher,plate folder or bending dies are applied as bending equipment.

The recommended temperature for bending is over 10°C.



4)Bending with panel bender



When plate folder is used to finish the Wisebond panel,dies shall be placed on with appropriate radius



 5) Riveting



Countersunk rivet can realize easy joint from one direction



6) Bolting



Considering from deformation limit,formul e>2D is the best calculation way of aperture D and distance from hole center to plate end.





8.PACKAGE



1.In wooden Pallet





2.In Bulk(with strong wooden fix the panel)



9.CERTIFICATIONS
