Specifications
Gas(N2,CO2,H2,He,etc.) transmission rate (GTR) of flexible materials test,Plastic material permeability analyser.N530 Gas permeability analyser for plastic package
N530 for the detection of gas permeability of various films, infusion bags and other packaging materials for O2, CO2, N2, He and other gases through the barrier properties.
It is designed and manufactured according to the standards of ISO 2556-2001, ISO15105-1, GB / T 1038-2000, ASTM D1434-82 (2003), YBB00082003 .
It has three independent testing chambers and independent temperature control system. The core is connected with computer through the USB. It can automatically judge and stop testing . The testing result is stable, curves of permeability rate ,temperature, pressure and different pressure will be shown at the same time. The test report will generate automatically while the data automatically stored. It also support TCP/IP protocol. There are three measuring range that can be enlarged..
Test principles:
N 530 Gas Permeation Analyzer designed using the principle of differential pressure method, preparation samples will be placed between in the test chamber with high / low pressure , and clamping it ,then make the whole test system to have a vacuum processed, input test gas the highpressure test chamber to ensure on both sides of the test samples have a constant pressure, the gas under the role of pressure pass through film from high-pressure chamber to the low pressure chamber to infiltrate, observe the changes pressure in low-pressure chamber to caculate barrier parameters of the sample.
Specifications
Measuring range | 0.02 ~ 50000 cm3/m2 /day/ 0.1Mpa(Through the expansion of volume cap can test 600000 cm3/m2 • day • 0.1Mpa) |
Measurement Accuracy | 0.01cm3/m2 /day /0.1MPa |
Temperature range | 15 ~ 45 °C (standard temperature of 23 °C) |
Temperature Accuracy | 0.01 °C |
Vacuum accuracy | 0.1Pa |
Test pressure | -0.1Mpa ~ +0.1 Mpa |
Test gas | O2, CO2, N2 and other gas |
Air Pressure | 0.1Mpa ~ 0.8Mpa |
Specimen size | Φ80mm, through an area of 50.24 cm2 |
Sample | 3(extension up to more pieces) |
Carrier gas interface | 1 / 8 inch |
Sample thickness | ≤ 2mm |
Power | AC 220V /50HZ |
Instrument weigh | 75 Kg. |
Gloss weight: | 90 Kg |
Dimension | 80 cm×56 cm×40 cm |
