HD sd Mobile DVR /3g &4ch h.264 wireless mobile DVR /Car Mobile DVR

Real-time video surveillance

Real-time image capturing

Audio/Video/Image recording & local storage

Data export via U-Disk

Local video preview and playback

Video playback on PC-side

Storage medium formatting

Parameter inquiry and setting

SW upgrade remotely

Real-time GPS tracking

Remote fault diagnosis

Video remote retrieval, download and playback

Trace playback

Vehicle CAN bus data

Voice intercom & Listen-in

Vehicle/Driver file management

Phone/calling function

LCD screen information display

Devices self-checking

Safety alarm function

Power cut-off /Sleeping mode/Mobile APP

Vehicles traveling data recorder

Accident data record

Drivers identification

Fatigue driving alarm & record

Over-speed alarm& record

Emergency alarm

GSM

3G/4G/WIFI(Optional)

GPS

SIRF IV,48 channels all-in-view tracking

GPS Sensitivity

-159dB

GPS Accuracy

<10m

Power Input

DC:+9V ~ +36V

Power Output

+12V@1A;+5V@1A

Working Temp

-30℃ ~ +70 ℃

Backup Battery

1000mAh/7.4V

Power consumption

<9W(No accessories)

Video & Audio

4/ 8 channels

Recording mode

Sound and video simultaneously recording

Audio Output

Single-channel audio output

Audio Compression

G711-A

Video Mode

PAL/NTSC

Video Compression

H.264

Video resolution

CIF/HD1/D1 for option

Video Display

1 picture,4 pictures,8 picture

Dimension

168*125*45mm

Weight

2kg

Speed Range

0 ~ 255 km/h

Speed Accuracy

Less than 0.5km/h

Record Capacity

360 hours traveling data, collect 5 times/sec, store 1 data/min

Data Storage

When device powered off, data can be saved 10 years at least

Sensor

Three-axis acceleration sensor

Video Playback

Support Local, PC playback SW playback

Support Time/Channel/Event playback mode

Storage

Dual card(each support 64GB)

Interfaces

1 GPS output,1GSM output, 1 WIFI output

6 switch inputs,1 speed testing input , 1 alarm input

1 RJ45,4 RD232,1 RS485,2 CAN port,1 USB port

2Analog inputs,2 outputs,

1 speak out,1Mic in,

2 SD card slots,1 TF card slot, 1SIM card slot, 1 IC card slot

1 RS232 for tachograph upgrade and 1 RS232 for DVR update
