Specifications
HMW-PE plastic sheet1.Stress crack resistant
2.Impact resistant
3.Abrasion resistant
4.Good sliding property
multi-function of HMW-PE plastic sheet
Description:
Ultra High Molecular Weight (UHMW) Polyethylene
is often referred to as the world’s toughest polymer. UHMW PE is a linear high density polyethylene which has high abrasion
resistance as well as high impact strength. UHMW PE is also chemical resistant and has a low coefficient of friction which make it highly effective in a variety of applications.
Physical property:
Property |
Standard |
Unit |
UHMWPE-M4 |
Physical Properties |
|||
Density |
GB1033-86 |
g/cm3 |
0.93 |
Water Absorption |
GB1034-86 |
% |
< 0.01 |
Max Working Temperature |
- |
°C |
90 |
Minimum Working Temperature |
- |
°C |
-269 |
Mechanical Properties |
- |
- |
- |
Tensile Strength |
GB1040-79 |
MPa |
21 |
Ultimate Tensile Strength |
GB1040-79 |
MPa |
38 |
Elongation |
GB1040-79 |
% |
12 |
Break Elongation |
GB1040-79 |
% |
340 |
E-Modulus |
GB1040-79 |
MPa |
820 |
Notched Impact Strength |
GB1843-80 |
KJ/m2 |
ok |
Bending Strength |
GB9341-88 |
MPa |
26 |
Bending E-Modulus |
GB9341--88 |
MPa |
760 |
Compression Strength (deformation 10%) |
GB1041-79 |
MPa |
27 |
Compression E-Modulus |
GB1041-79 |
MPa |
550 |
Shear Strength |
GB1041-79 |
MPa |
33 |
Hadrness |
GB2411-80 |
Shore D |
65 |
Static Coefficient of Friction |
GB10006-88 |
- |
0.07-0.15 |
Dynamic Coefficient Friction |
GB10006-88 |
- |
0.07-0.11 |
Thermal Properties |
- |
- |
- |
Coefficient of Linear Expansion |
GB1036-89 |
°C-1 |
1.5×10-4 |
Coefficient of Heat Conductivity ( 23 °C ) |
GB3399-82 |
Cal/cm sec °C |
8.5×10-4 |
Special Heat ( 23 °C) |
GB3399-82 |
Cal/g°C |
0.44 |
Electrical Properties |
- |
- |
- |
Volume Resistivity |
GB1410-78 |
Ohm cm |
>1015 |
Surface Resistivity |
GB1410-78 |
Ohm |
>1015 |
Dielectric Constant ( 1MHZ ) |
GB1409-78 |
- |
3 |
Dielectric Strength |
GB1408-78 |
Kv/mm |
70 |
P.S. two colored is available for you to observe the two side application. For comparison.
