Metal Separator

Metal Separator thumbnail-1
Metal Separator photo-1
US$ 4,400 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
SINBON
Model Number:
MS-100R
Contact Supplier Request Quote Chat Now
Shanghai Harvest Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name SINBON
Model Number MS-100R



Product Description



Metal Separator is based on electric induction theory to detect metals, which can detect ferrous metals and non-ferrous metals. Metals includes iron, Copper, aluminum, tin, stainless steel etc. Because metals mixed in recycle material, it will be very easy to destroy production equipment; Metal impurity can result in injection molding machine and extruder screw, cylinder body, nozzles broken; Metal impurity maybe hurt consumers, it will result in huge claims. Therefore, using recycle material must consider risk of metal impurity and try to decrease this risk. The simple way is use metal separator to detect and automatic reject these metal impurity.



METAL IMPURITY HARMNESS

  • Often jam injection molding machine’s nozzles
  • Damage the screws
  • Scratch cylinder of injection molding machine
  • Scratch products and leave traces
  • Jam mold infeed nozzles
  • Increase pressure of hot flow path and block flow
  • Scratch mould mirror
  • Break the precise mould
  • Unqualified products occur due to products mixed metals



METAL SEPARATOR ADVANTAGES

  • Protect Production Equipment
  • Improve production efficiency
  • Improve the utilization efficiency of raw material
  • Improve product quality
  • Decrease production equipment repair costs and shutdown losses



METAL SEPARATOR WORKFLOW

  • Material come from hopper or feeder freefall to pipe of metal detector, if no metals in material, material will go through metal detector to qualified product pipe directly; if detected metals, metal detector separator will automatic block the pipe of qualified products, so these material mixed with metals will flow to unqualified product pipe; When finished this, separator will open the pipe of qualified products immediately. Sensitivity of metal detector can be adjusted according to requirement.



FEATURES

  • Germany Technology and made in China, it can automatic separator ferrous and non-ferrous metals from raw materials.
  • High sensitivity, it can detect 1.2mm metals granules and metal wires
  • Raw material can be filled to metal detector via automatic feeder, material mixed metals will be rejected out
  • Metal Separator can be installed on production equipment directly or working at side of pulverizer, pulverizing material can go through metal detector directly and separate the metals from material to avoid metals go into injection molding machine
  • Operation is simple; Hopper and scaffold are optional



APPLICATION

  • Widely used in plastic granules metal detection and automatic separate the metal impurity



SPECIFICATION

  • Model No.: MD-100R
  • Pipe Diameter: Φ100mm
  • Sensitivity: Φ1.2mm
  • Flow Rate: 2000kg/h
  • Rejection Time: 0.3-5seconds (adjustable)
  • Material Temperature: ≤80℃
  • Working Environment Temperature: -20℃-60℃
  • Material of Machine: A3 steel plate with painted
  • Contact Parts Material: Nylon, carbon steel or stainless steel, aluminum
  • Air Source: 3-6bar, 8mm air pipe
  • Air consumption: 0.4L/time
  • Power: 10W
  • Power Wire: 3m, triangle plug
  • Dimension: 450x310x430mm(L*W*H)
  • Power Source: AC220V;50HZ;1P



OPTIONAL PARTS

  • Hopper
  • Moveable scaffold
