Specifications
1x2 Welded Wire Mesh Panel1.ISO9001:2000
2.wire diameter:BWG17-3 or others
sh:1/2''--6''
4.use:fence,construction,bu
1x2 Welded Wire Mesh Panel
1. Brief Introduction:
Welded Wire Mesh Panel/1x2 Welded Wire Mesh Panel is made of superior quality welded mesh, with flat even surface, firm structure, be used extensively in building, food, agriculture and so on.
2. Material: steel wire, stainless steel wire or iron wire
3. Assortments available:
Welded Stainless Steel Wire Mesh Panels
Galvanized Welded Mesh Panels
Hot-dip Zinc Plating Welded Mesh Panels
4. Surface Treatment:
hot dipped galvanized, cold (electro) galvanized, and PVC coated
5. Application:
Welded steel bar grating panels are widely used in construction reinforcement,
the ground for the tunnels, bridges, highway, airport and wharf, also in construction
of wall body.
Welded mesh fence panels are utilized as guards in buildings and factories, as
animal enclosure and fence in agriculture; it is also used in horticulture industry as tree guards, plant protection.
6. Specifications
Welded Mesh panel | ||
Opening |
Wire Diameter |
|
In inch |
In metric unit(mm) |
|
1/4" x 1/4" |
6.4mm x 6.4mm |
22,23,24 |
3/8" x 3/8" |
10.6mm x 10.6mm |
19,20,21,22 |
1/2" x 1/2" |
12.7mm x 12.7mm |
16,17,18,19,20,21,22,23 |
5/8" x 5/8" |
16mm x 16mm |
18,19,20,21, |
3/4" x 3/4" |
19.1mm x 19.1mm |
16,17,18,19,20,21 |
1" x 1/2" |
25.4mm x 12.7mm |
16,17,18,19,20,21 |
1-1/2" x 1-1/2" |
38mm x 38mm |
14,15,16,17,18,19 |
1" x 2" |
25.4mm x 50.8mm |
14,15,16 |
2" x 2" |
50.8mm x 50.8mm |
12,13,14,15,16 |
panels length: 2m-5m;width: 0.5m ,1m,1.5m,2.0m | ||
Welded Wire Mesh Specifications | ||||
Wire Diameter mm |
mesh hole |
weight ( m ) |
width( m ) |
|
diameter space mm |
Wire space mm |
|||
10 |
100--500 |
30--300 |
1--8 |
0.5--3 |
9 |
100--500 |
30--300 |
1--8 |
0.5--3 |
8 |
100--500 |
30--300 |
1--8 |
0.5-3 |
7 |
50--200 |
20--300 |
1--8 |
0.5-3 |
6 |
50--200 |
20--200 |
1--8 |
0.5-3 |
5 |
50--200 |
10-200 |
1--8 |
0.5-3 |
4 |
30--200 |
10--200 |
1--8 |
0.5-3 |
2-4 |
25--100 |
10--100 |
1--6 |
0.5--3 |
It can be made by customers' requirements. | ||||
