Dry advantages of non-contact voltage regulator:
1, small size, light weight, suitable for long-distance transport, reduce your transp Enhance your competitive edge supplier of the best regulator
Detailded discription
Our company is a legally qualified production manufacture factory, which mainly manufactures dry-type non-contact voltage regulator, and dry-type transformers, we provide direct sales and OEM contract manufacturing services, welcome your advice.
1, the stable, mature products, reduce your maintenance costs after the sale and time;
2, whole no contact, no brush, no wear, no maintenance once installed;
3, a wide input voltage range can be customized non-standard ± 60% input voltage range;
4, high output voltage accuracy ± 1%;
5.The AVR’s can match any load type, especially unmanned operation of equipment in telecommunication centers.
6, the regulator is fast, able to adjust the voltage within 40ms of work;
7, three-phase independent control of voltage, non-interfering, anti-lightning.
8, is widely used in communication base stations, telecommunications / broadcasting network, highways, machinery and equipment.
Main technical parameters
Technical specification |
|
|
|
Three phases |
Single phase |
specification |
10KVA~2000KVA |
1KVA~600KVA |
input voltage |
304v~456v |
176v~264v |
output pre cision |
±(1~5)% can adjust |
±(1~5)% can adjust |
phase |
3 |
1 |
insulated strength |
2000V, 1 minute does not have the puncture |
|
Insulated Electric Resistance |
> 2MΩ |
|
Efficiency |
> 98% |
|
Waveform Deformation |
<0.1% |
|
Working Frequency |
50~60Hz |
|
Time for Stabilization |
<100ms |
|
Digital Voltmeter/Ammeter |
Yes |
|
Digital Frequency |
Yes |
|
Overload protection function |
Yes |
|
low load protection function |
Yes |
|
over current protection function |
Yes |
|
short current protect function |
Yes |
|
Output Delay Function |
Yes |
|
phase sequence protection function |
Yes |
|
cooling system |
Fan cooling |
|
Package |
Export Wooden Case |
|
