1000VA AC single phase servo motor voltage stabilizer /regulator
1.General introduction:
The servo motor Voltage Microcomputer Regulator is an energy-saving product developed by Goter Power Hi-tech,Co.,Ltd with absorbing the advanced technology of western Europe. It provide with two systems of manual/automatic dual control, could be directly output and stabilizing output, With the functions of over/under-voltage protection, delay and error protection , It is reliable and suitable for your project.
2.Defensive Function:
1.Servo motor control with carbon brush.
2.Dynamic stabilization precision±3~5%
3.Response time 3~5second
4.Display: pointer type
5.Regular maintenance
6.Technical Parameter:
working method |
Logic pulse circuit control |
|
AC Input |
Rated voltage |
220V |
Voltage range |
150V-250V (Wider range can be customized) |
|
Frequency |
47Hz~63Hz |
|
Power factor |
0.95~1 |
|
AC Output | ||
|
Output accuracy
|
1- 5% (Adjustable ) |
|
Waveform distortion |
Compared with input zero distortion |
|
Efficiency |
≥98% |
|
Response Time |
≤0.5S |
|
Voltage |
LED digital display |
|
Protection |
Over voltage |
the output voltage will stabilize at 380V±3-5%
|
Low voltage | ||
Over load |
Cut power |
|
short |
compensate power |
|
Overload Capability |
150%(10s) |
|
Noise(with 1m distance) |
<45dB |
|
Input/output connection type |
Terminal |
|
Overload capacity |
150% ( 10 s ) |
|
Noise (1 m distance) |
<45dB |
|
Cooling system |
Fan cooling |
|
Environment |
Temperature |
0°C-45°C |
Humidity |
0-95%( Non-condensing) |
|
7. Factory:
Application : CNC equipment , The Laser incising machine , Printing/Medical equipment , etc.
Certificate:
