380V SBW voltage regulator 450KVA / 380V AC AVR 450KVA
1.Sphere of application:
CNC equipment SMT equipment Laser cutting machine
Electronic manufacturing equipment The Laser incising machine
Precision CNC lathes Printing/Medical equipment
2.General introduction:
The SBW voltage regulator is an energy-saving product developed by Goter Power Hi-tech,Co.,Ltd
with absorbing the advanced technology of western Europe. It provide with two systems of manual/
automatic dual control, could be directly output and stabilizing output, With the functions of over/
under-voltage protection, delay and error protection , It is reliable and suitable for your project.
3.Defensive Function:
1) Overload Protection 2) Overvoltage/Under voltage Protection
3) AC Phase Lack/Miscount phase Protection 4) SOVP Protection
5) Short-circuit Protection 6) The Bypass Protects Device
4.Advantages:
1) Wide Range of Voltage Input 2) Higher Regulation Accuracy
3) Three-phase Sub-tone 4) Faster Response Time
5) Strong Capacity of Overload 6) High Efficiency of output
5.Technical Parameter:
| working method | Logic pulse circuit control | |
| AC Input | Rated voltage | 380V/220V |
| Voltage range | ±10%~±15% (Wider range can be customized) | |
| Frequency | 47Hz~63Hz | |
| Power factor | 0.95~1 | |
| AC Output | rated voltage | 380V/220V |
| Output accuracy | 1- 5% (Adjustable) | |
| Waveform distortion | Compared with input zero distortion | |
| Efficiency | ≥95% | |
| Response Time | ≤0.5S | |
| Voltage | LED digital display | |
| High voltage | LED alarm and cut off the input voltage | |
| Low voltage | LED alarm and cut off the input voltage | |
| Protection | Over voltage | Constant power, the output precision will higher |
| Low voltage | Constant power, the output precision will lower | |
| Over load | Cut power | |
| short | Cut power | |
| Overload Capability | 150%(10s) | |
| Noise(with 1m distance) | <45dB | |
| Input/output connection type | Terminal | |
| Overload capacity | 150% ( 10 s ) | |
| Noise (1 m distance) | <45dB | |
| Cooling system | Fan cooling | |
| Environment | Temperature | 0°C-45°C |
| Humidity | 0-95%( Non-condensing) | |
6.Certifications:
7.Factory
