XF-ZG Aluminum-Plastic Tube Making Machine
Introduction:
It is a tube body making machine ,it can not only make aluminum-plastic tube(ABL), but also plastic tube(PBL). toothpaste tube making body machine can be combined with our semi-automatic shoulder injection become an tube production line.
This machine is controlled by plc with the human-computer interface of touch screen, is featured with stable performance, simple manipulation and easy adjustment.
It will be widely used in the production of packaging tubes of toothpaste, food, drug, cosmetic and other types of pastes or latexes products.
Main Technical Parameters:
Item |
Parameters: |
Power Supply |
220(380)VAC/50Hz |
Power |
20Kw |
Tube-Making Speed |
18m/min,100pcs/min(max) |
Tube Diameter |
Φ12.7-50mm |
Tube Length |
45-200mm |
Air Supply |
0.5-0.7MPa ,through oil water treatment |
Water Supply Requirement |
>0.2MPa, Flux 5-6liter/min , Temperature <20°C ,soft water |
Machine size |
2800×980×1900mm |
Weight |
1800Kg |
Picture of the machine:
Packaging & Transportation:
Outer package: standard exported wooden case or according to customers’ requirement.
Inner package: stretch film
Transport by ship, by plane or by land.
XINGFEIPACK
------ One Brand Made in China and Moving Towards the World
Shanghai Xingfei Packaging Machinery Co., Ltd. is a professional manufacturer engaged in the research and development of packaging machinery and food machinery, and we are a member of the Chinese Food and Packaging Machinery Industrial Association.
