Specifications
Self-amalgamating tape made of PIB rubberTensile strength: 1.7MPA
Elongation: 600%
Quality guarantee!
Hot selling!
Insulation tape, self fusing tape , self amalgamating tape, splicing tape, high voltage tape
Features
• Non-vulacanizing and highly conformable
• Physical and electrical properties are unaffected by the degree of stretch
• Can be stretched up to 800% to make void-free
• Moisture-resistant insulation, self amalgamating tape
• Excellent electrical properties
Application
• Primary insulation for make stress cones on cables up to 35KV
• Primary electrical insulation for cable jointing and terminating up to 69KV with up to 90°c. Continuous operating temperatures and 130°c emergency overload temperature.
Sizes
19mm x 0.76mm x 9.14m
25mm x 0.76mm x 9.14m
38mm x 0.76mm x 9.14m
50mm x 0.76mm x 9.14m
Special size can be requested.
| Model | Tensile strength | Elongation | Disruptive voltage |
| (Mpa) | (%) | KV/mm | |
| KE10 | 1.5 | 500 | 5 |
| KE20 | 1.5 | 600 | 11 |
| KE30R | 1.8 | 800 | 32 |
| KE30P | 1.8 | 800 | 35 |
Quality warranty!
Competive prices!
Hot selling!
