Neutral Current Transformer

Neutral Current Transformer thumbnail-1
Neutral Current Transformer photo-1
US$ 10 - 60 MOQ: 100 Units
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
MAXWEL
Model Number:
MES-62/B
Contact Supplier Request Quote Chat Now
Yueqing Maxwel Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name MAXWEL
Model Number MES-62/B
Usage Current
Phase Three
Coil Structure Toroidal
Coil Number Autotransformer

Specifications

Primary current 5A-3000A
Secondary current 5A 1A
Class 0.5/1.0
-10 degree to 50 degree
Competitive price

 MES current transformer series:



  • The MES series of current transfomer are convenient for mounting in many ways.
  • The most current transformer need the special mounting and the EMS series used the mounting of DIN typing without a lot of time.
  • The protective cover for the terminal block used the switching device with safety and quick



MES tecnicial specifications:



Primary current: 5A-3000A

Secondary current: 5A/1A

Standard approval: IEC44-1/BS7626/VDE0414

Maximum voltage: 0.72/3kv

Frequency: 50/60hz

Rated load: 2.5VA/5VA/10VA/15VA

Class: 0.5/1.0

Short-time thermal current: ith=60*Ih

Rated security coefficient Fs<5





Model

Nominal current ratio

Burden VA


Class 0.5

Class 1

MES-62/B

5/5

1.5

2.5
MES-62/B

10/5

1.5

2.5
MES-62/B

15/5

1.5

2.5
MES-62/B

20/5

1.5

2.5
MES-62/B

25/5

1.5

2.5
MES-62/B

30/5

1.5

2.5
MES-62/B

40/5

1.5

2.5
MES-62/B

50/5

 1.5

 2.5
MES-62/B

60/5

 1.5

 2.5
MES-62/B

75/5

 1.5

 2.5
MES-62/B

100/5

 1.5

 2.5
MES-62/B

 150/5

 1.5

 2.5



neutral current transformer

neutral current transformer
