transformer

Specifications

Split Core Current Transformer
Primary current 100A-5000A
Secondary current 5A 1A
Class 0.5/1.0/3/0
Guaranteed quality

Split core current tranformr MS1 series:

• Can have been especially designed to facilitate their installation in new or already existing networks need current transformer
• Iron core of this current transformer can be easily opened and they can be installed and connected without any supply interruption
• As the most professional low voltage current transformer manufacture in China, our current transformer line cover nearly all the models current transformer you can buy in China, even many of the supplier you find here buy from us
• Can make nearly all the components of the current transformer, current transformer casing, current transformer iron core and current transformer accessories by ourself
• Popular in Greece,Italy,Russian,South Africa,Brazil, etc



 MS1 features:



Small size and easy mounting

Wide inner window, allowing clamping of big cables or bus bar

Wide range of sizes to accommodate all the existing installation

High accurancy and reliability





MS1 tecnicial specifications:



Primary current: 100A-5000A

Secondary current: 5A/1A

Standard approval: IEC44-1/BS7626/VDE0414/VL94

Maximum voltage: 0.72/3kv

Frequency: 50/60hz

Rated load: 1VA-30VA

Class: 0.5/1.0/3.0

Short-time thermal current: ith=100*in

Rated security coefficient Fs<5





Model	Nominal current ratio	Burden VA		Weight (KG)
		Class 0.5	Class 1
MS1	100	0.5	1	0.75
MS1	150	0.5	1	0.75
MS1	200	0.5	1.5	0.75
MS1	250	0.5	2	0.75
MS1	300	1.5	3.75	0.75
MS1	400	2.5	6	0.75
